| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2600 x 2000 x 750 mm | |
|---|---|---|
| Worktop thickness | 25 mm | |
| Modesty panel height | 400 mm | |
| Knee clearance height | 680 mm | |
| Knee clearance width | 1600 mm | |
| Left return cabinet dimensions | 1200 x 600 x 650 mm | |
| Right support leg cross-section | 150 x 150 mm | |
| Edge banding thickness | 2 mm | |
| Cable grommet diameter | 80 mm | |
| LED light strip width | 10 mm | |
| Worktop overhang at front | 50 mm | |
| Leveling glide adjustment range | 15 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 136 kg | |
|---|---|---|
| Drawer slide load rating per drawer | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 100000 cycles | |
| Surface scratch resistance rating | 3 N | |
| Net weight (assembled) | 100 kg | |
| Recommended user count | 1 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop substrate | E0-grade MDF core with dark wood veneer finish | |
|---|---|---|
| Side return front panel | Top-grain tan leather upholstery over MDF core | |
| Modesty panel | Vertical fluted solid wood slats with matte dark finish | |
| Structural trim and legs | Powder-coated dark grey metal with solid wood blocking | |
| Edge banding | 2 mm ABS matching worktop finish | |
| Integrated LED strip | Low-voltage 3000K warm white LED array | |
| Drawer slides | Cold-rolled steel full-extension soft-close slides | |
| Door hinges | Soft-close concealed steel hinges | |
| Leveling glides | Nylon base with zinc-plated steel threaded stem | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Ambient under-desk lighting | Recessed LED strip runs full modesty panel length, hardwired to desk power input | |
|---|---|---|
| Left return storage | Integrated credenza with locking file drawer and storage cabinet for office supplies and files | |
| Cable management | Dual desktop grommets with under-desk cable tray to route power and data cords out of sight | |
| Leveling adjustment | Threaded glides at each leg base adjust up to 15 mm to stabilize desk on uneven floors | |
| Drawer operation | Full-extension soft-close drawers open fully for file access and close silently without slamming | |
| Modesty panel coverage | Full-width fluted panel blocks view of seated user's legs from office entry direction | |
| Work surface layout | Continuous L-shaped top provides main work zone plus secondary return surface for peripherals or meeting space | |
| Storage security | Concealed central lock secures all return cabinet drawers and doors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Designed for CEO, director or senior manager private workspaces, presenting a high-end professional image | |
|---|---|---|
| High-end home office | Suitable for premium residential home office setups requiring refined aesthetic and full storage | |
| Corporate boardroom ancillary space | Usable as a side work surface or executive work station in high-end boardroom suites | |
| Recommended seating pairing | Pairs with high-back leather executive chairs with 500 mm seat height | |
| Layout recommendation | Position with left return against side wall to create clear guest-facing front work zone | |
| Surface use guidance | Water and stain resistant finish supports daily office use with laptops, documents and desk phones |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural performance verification | |
|---|---|---|
| EN 13722:2004 | Office furniture storage units strength and durability, applicable to return cabinet performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for performance of integrated return cabinets |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk construction and finish quality | |
|---|---|---|
| GB/T 4897-2015 | Particleboard/MDF performance requirements, applicable to wood-based panel substrate quality | |
| GB 18584-2001 | Indoor decoration material formaldehyde emission limits, applicable to panel material environmental compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk construction and finish quality; 2. GB/T 4897-2015: Particleboard/MDF performance requirements, applicable to wood-based panel substrate quality; 3. GB 18584-2001: Indoor decoration material formaldehyde emission limits, applicable to panel material environmental compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
