Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1250 x 700 x 420 mm | |
|---|---|---|
| tabletop thickness | 28 mm | |
| pedestal base bottom diameter | 520 mm | |
| pedestal base top diameter | 380 mm | |
| pedestal open cutout size | 260 x 220 mm | |
| tabletop edge radius | 350 mm | |
| tabletop overhang from base edge | 365 mm | |
| floor clearance under base cutout | 12 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| product net weight | 65 kg | |
|---|---|---|
| distributed tabletop static load capacity | 45 kg | |
| surface stain resistance rating | Grade 4 | |
| metal base finish scratch resistance | Grade 3 | |
| floor protection pad load rating per pad | 25 kg | |
| warranty period | 1 year | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| tabletop core | High-density MDF or sintered stone composite | |
|---|---|---|
| tabletop finish | Matte white UV-cured lacquer or sealed matte sintered stone | |
| pedestal structure | 1.5 mm thick cold-rolled steel formed truncated cone | |
| pedestal finish | Matte black scratch-resistant powder coating | |
| tabletop-base connector | M8 steel hex bolts with lock washers | |
| floor protection pads | 5 mm thick non-marking felt pads affixed to base bottom | |
| cutout edge treatment | Smooth rounded powder-coated edge finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| assembly requirement | Knock-down assembly with included Allen key and pre-drilled holes | |
|---|---|---|
| floor protection | Integrated felt pads prevent scuffing on hardwood, tile, and laminate flooring | |
| surface utility | Smooth non-porous tabletop supports easy wipe-clean for spills and daily use | |
| base stability | Wide flared pedestal base eliminates tipping risk under standard household loads | |
| placement compatibility | Low profile designed for placement directly in front of standard 450 mm seat height sofas | |
| open cutout feature | Rounded front cutout allows decorative object display inside the pedestal base | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| residential living room | Placed in front of 3-seater or L-shaped sofas for beverage, decor, and remote placement | |
|---|---|---|
| modern office lounge | Used in reception waiting areas and employee break spaces for guest refreshment placement | |
| small urban apartment | Compact oval footprint fits narrow living spaces without sharp corner hazards | |
| showroom display | Used as a centerpiece in furniture showrooms and interior design staging | |
| hotel guest suite lounge | Installed in premium hotel suite seating areas for guest convenience |
EU Market Access Requirements* EN Standards
| furniture mechanical safety | EN 12521:2015 | |
|---|---|---|
| surface finish durability | EN 15186:2012 |
Standards applicable to China-market projects
| tabletop surface performance | GB/T 4893.4 | |
|---|---|---|
| metal base coating performance | GB/T 1993 | |
| furniture structural stability | GB/T 10357.1 |
This product must meet the following technical requirements: 1. tabletop surface performance: GB/T 4893.4; 2. metal base coating performance: GB/T 1993; 3. furniture structural stability: GB/T 10357.1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
