PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1270 × 700 × 470 mm
Tabletop thickness	18 mm
Frame tube cross-section	20 x 20 mm
Frame wall thickness	1.2 mm
Under-large-table floor clearance	100 mm
Nesting insertion depth	450 mm
Height difference between tabletops	90 mm
Large tabletop overhang past frame	30 mm
Floor protection pad diameter	20 mm
Finished Top Thickness	45 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Large table static distributed load capacity	100 kg
Total set net weight	37 kg
Frame static load rating per leg	30 kg
Powder coat scratch resistance	2H pencil hardness
Top surface heat resistance	120 °C
Recommended maximum user weight for edge sitting	80 kg
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles
Hinge Opening Life	Acceptance target 80000 cycles
Top Abrasion Reference	Acceptance target ≥4,000 abrasion cycles or finish-system test

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Support frame	Powder-coated black carbon steel tubing
Large tabletop	Dark matte marble-effect sintered stone/laminate panel
Small tabletop	Light matte stone-effect sintered stone/laminate panel
Frame joints	MIG-welded steel connections with hidden assembly hardware
Foot pads	Injection-molded non-slip polyethylene floor protectors
Tabletop edge banding	Matching color sealed PVC/ABS edge trim
Frame surface finish	Matte black electrostatic powder coating
Assembly hardware	Zinc-plated steel bolts and allen key fasteners
Primary Panel Thickness	25 mm; load-bearing top may use 40 mm composite build-up
Edge Band Thickness	2 mm
Metal Frame Wall Thickness	2 mm cold-rolled steel
Primary Connector Specification	Reference M6-M8 with at least 2 fixing points per main support

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Space-saving nesting function	Small table slides 450 mm under the large table to reduce footprint when not in use
Dual-surface flexible use	Two independent tabletops support separate placement of drinks, decor and serving items
Leveling adjustment	Each leg fitted with a rotatable foot pad to adjust for uneven floor surfaces
Easy surface maintenance	Smooth non-porous tops wipe clean with a damp cloth without special treatments
Knock-down assembly	Frames and tops assemble with included hardware without specialized power tools
Floor protection	Soft polymer foot pads prevent scuffs and scratches on tile, wood and vinyl flooring
Flexible configuration	Tables separate for use as side tables, or nest as a single central living room table
Cable Management Capacity	Reference capacity 10power/data cables; tray load 10 kg
Reference Reassembly Count	Main joints should support 5controlled assembly cycles

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	2100× 1100× 300 mm
Reference Packaged Gross Weight	90 kg/set in 2 cartons
Reference Packaging Volume	0.55 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Residential living room	Place as central table in front of 3-seat sofas for drinks, decor and media accessories
Small apartment spaces	Use nesting function to reduce footprint when extra surface area is not required
Open-plan lounge areas	Separate tables for flexible serving during gatherings or casual events
Modern industrial interiors	Match with dark metal, neutral fabric and minimalist decor schemes
Studio office reception zones	Use as a low guest table in reception waiting areas for lightweight refreshments
Recommended floor types	Suitable for tile, polished concrete, hardwood and luxury vinyl plank flooring

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 12521:2015	Safety, strength and durability requirements for domestic dining and living room tables
EN 13722:2004	Test methods for furniture strength and stability for domestic seating-area tables

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to laminate/composite top panels
GB/T 1732-2020	Determination of impact resistance of paint films, applicable to powder-coated metal frames
GB/T 4893.8-2013	Test for surface abrasion resistance of furniture, applicable to tabletop finishes

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to laminate/composite top panels;
2. GB/T 1732-2020: Determination of impact resistance of paint films, applicable to powder-coated metal frames;
3. GB/T 4893.8-2013: Test for surface abrasion resistance of furniture, applicable to tabletop finishes;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · NCT-OVL-2PC-BLKFRAME

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · NCT-OVL-2PC-BLKFRAME

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · NCT-OVL-2PC-BLKFRAMEOpen Export Tool

Quick Actions

Post an RFQ

Product Description

This two-piece oval nesting coffee table set features a sleek, modern industrial silhouette defined by its open black metal frame and complementary two-tone table tops. The larger oval table anchors the set, with a geometric square smaller table sized to slide partially beneath it to create a streamlined, layered profile when nested, or to separate fully for independent use across a space. The set’s frame is constructed from powder-coated black carbon steel tubing, with MIG-welded joints secured by hidden assembly hardware and finished in a matte black electrostatic powder coat with scratch resistance matching 2H pencil hardness. Each leg terminates in an injection-molded non-slip polyethylene foot pad that protects flooring and rotates to adjust for uneven surfaces. The large table features a dark matte marble-effect sintered stone or laminate top, while the smaller table uses a light matte stone-effect sintered stone or laminate top, both finished with matching color sealed PVC or ABS edge trim. Table tops are smooth and non-porous, with a surface heat resistance of 120°C, and support a static distributed load of 100 kg for the large table, with a uniform distributed static load reference of 150 kg for top surfaces. Core functional benefits include its space-saving nesting design, which lets the smaller table slide 450 mm under the larger unit to minimize footprint when extra surface space is not needed. The two independent tops support flexible placement of drinks, decor, and serving items, and can be separated for use as individual side tables, or arranged together as a central coffee table. Surfaces wipe clean easily with a damp cloth without specialized cleaning products, and the soft polymer foot pads prevent scuffs and scratches on tile, wood, polished concrete, and luxury vinyl plank flooring. Assembly is completed with included zinc-plated steel bolts and allen key fasteners, requiring no specialized power tools. This set is well suited for residential living rooms as a central table positioned in front of 3-seat sofas, for small apartment spaces where footprint flexibility is a priority, for open-plan lounge areas to support flexible serving during gatherings, for modern industrial interiors aligned with dark metal, neutral fabric, and minimalist decor, and for studio office reception zones as a low guest table for lightweight refreshments. For procurement, note the set ships in two cartons with a packaged gross weight of 90 kg, requires 40 minutes of assembly time per set, and supports an edge sitting maximum user weight of 80 kg; specify the model NCT-OVL-2PC-BLKFRAME for orders, as the set is offered unbranded.

Two-Piece Oval Nesting Coffee Table Set with Black Metal Frame Specifications
