Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 800 × 800 × 500 mm | |
|---|---|---|
| Overall set footprint (nested) | 800 x 800 x 500 mm | |
| Large table diameter | 800 mm | |
| Large table total height | 450 mm | |
| Large tabletop thickness | 18 mm | |
| Small table diameter | 600 mm | |
| Small table total height | 500 mm | |
| Base spread diameter (per table) | 580 mm | |
| Vertical support column section | 30 x 30 mm | |
| Base foot length (prong) | 280 mm | |
| Nesting clearance between tables | 50 mm | |
| Table edge radius | 9 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Set total net weight | 18 kg | |
|---|---|---|
| Large tabletop distributed static load | 23 kg | |
| Small tabletop distributed static load | 15 kg | |
| Base floor contact static load rating | 50 kg per table | |
| Surface horizontal impact resistance | 10 J | |
| Recommended maximum user weight for temporary edge seating | 100 kg | |
| Finish abrasion resistance (tabletop) | 2000 cycles | |
| Powder coating salt spray resistance (base) | 48 hours | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Large tabletop substrate | 18mm MDF core with white marble-look melamine laminate | |
|---|---|---|
| Small tabletop substrate | 18mm MDF core with matching white marble-look melamine laminate | |
| Table edge banding | 1mm matching PVC edge banding | |
| Vertical support columns | 30x30mm square steel tube, matte black powder-coated finish | |
| Three-prong base feet | 2mm thick flat steel bar, matte black powder-coated finish | |
| Floor contact pads | 5mm thick non-slip rubber pads at each prong end | |
| Connection hardware | M8 zinc-plated steel bolts and pre-installed threaded inserts | |
| Surface finish texture | Low-sheen smooth marble-vein finish with subtle gray veining | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Nesting storage function | Small table slides partially under large table to reduce footprint to 0.64 sqm | |
|---|---|---|
| Dual-height use function | Two distinct table heights support separate drink, decor and reading material placement | |
| Independent table use | Both tables can be separated and used as standalone side tables in different room zones | |
| Floor protection function | Rubber base pads eliminate metal-to-floor contact and prevent skid marks on hard flooring | |
| Assembly requirement | Knock-down assembly requires attaching base columns to tabletop with included hardware | |
| Surface maintenance | Non-porous laminate surface allows wipe-clean with damp cloth, no sealing required | |
| Weight distribution design | Three-prong base spreads load evenly across three floor contact points to prevent wobble on low-pile carpet | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Primary application space | Residential living rooms placed on area rugs in front of upholstered sofas | |
|---|---|---|
| Secondary application space | Small apartment lounge areas or studio open-plan living zones | |
| Target user group | Urban homeowners and renters seeking minimalist modern accent furniture | |
| Recommended decor pairing | Neutral upholstered sofas, light neutral wall finishes, textured low-pile rugs | |
| Use case suitability | Holding drinks, small decor objects, books, and table lamps for daily living room use | |
| Commercial secondary use | Lounge areas in boutique offices, hotel lobbies, and modern cafe waiting spaces |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic tables, applicable for load testing | |
|---|---|---|
| EN 13722:2004 | Furniture – Test methods for surface finish resistance to wear and staining |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to tabletop substrate performance | |
|---|---|---|
| GB/T 17657-2013 | Test methods for wood-based panels, applicable for surface wear and formaldehyde verification | |
| GB/T 19001-2016 | Quality management system guideline for consistent manufacturing tolerance control |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to tabletop substrate performance; 2. GB/T 17657-2013: Test methods for wood-based panels, applicable for surface wear and formaldehyde verification; 3. GB/T 19001-2016: Quality management system guideline for consistent manufacturing tolerance control; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
