Automatic mm / inch conversion · Core engineering specifications
| Overall extended console dimensions | 3400 x 420 x 450 mm | |
|---|---|---|
| Main console body dimensions | 2200 x 400 x 350 mm | |
| Left extended side shelf dimensions | 1200 x 420 x 150 mm | |
| Drawer internal dimensions per compartment | 700 x 360 x 200 mm | |
| Top surface thickness | 12 mm | |
| Carcass panel thickness | 18 mm | |
| Back panel thickness | 9 mm | |
| Floor clearance | 10 mm | |
| Matching round coffee table dimensions | 900 x 900 x 400 mm | |
| Matching small round side table dimensions | 450 x 450 x 500 mm | |
| Upholstered ottoman dimensions | 400 x 400 x 420 mm | |
| Cable management opening diameter | 60 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Console top static load capacity | 80 kg | |
|---|---|---|
| Drawer static load per compartment | 15 kg | |
| Sintered stone surface heat resistance | 180 °C | |
| Sintered stone surface abrasion resistance | 6000 cycles | |
| Total set net weight | 140 kg | |
| Drawer slide durability | 50000 open/close cycles | |
| Available finish variants | 5 | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Console and coffee table top | 12mm polished white sintered stone with gray marble veining | |
|---|---|---|
| Console main cabinet body | 18mm E0-grade high-density fiberboard with white matte lacquer finish | |
| Console frame and lower side shelf | Engineered wood with matte black baked paint finish | |
| Coffee table base | Cylindrical engineered wood frame with matte black lacquer finish | |
| Small side table structure | Powder-coated carbon steel frame with black matte finish | |
| Ottoman upholstery | Woven houndstooth polyester fabric | |
| Ottoman padding | 40mm high-density polyurethane foam, 35kg/m³ density | |
| Drawer hardware | Cold-rolled steel soft-close full-extension drawer slides | |
| Cabinet base pads | Non-slip PVC floor protection pads | |
| Surface coating | Low-VOC odorless polyurethane lacquer | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Three soft-close drawer storage compartments | Push-to-open operation, no visible handles for seamless front facade, silent soft-close retraction | |
|---|---|---|
| Extendable left side open shelf | Fixed low-profile open platform for decorative display, extends total console length | |
| Rear cable management cutout | Recessed opening at rear of console to route TV and media device cords | |
| Floor-level placement design | Low profile optimized for positioning below wall-mounted televisions 400 mm above console top | |
| Coordinated living room set configuration | Console paired with matching round coffee table, small side table and upholstered ottoman for complete living room layout | |
| Scratch and heat resistant top surface | Sintered stone top resists scuffs from decor and heat from small household appliances | |
| Reversible shelf installation option | Left extended shelf can be installed on right side for flexible room layout | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Modern residential living room | Positioned below wall-mounted TVs from 65 to 85 inches for media storage and display | |
|---|---|---|
| Open-plan apartment layouts | Asymmetric extendable length fits wide feature walls in compact to medium living spaces | |
| Light luxury contemporary interiors | Black and white stone finish matches minimalist, modern Italian and Scandinavian decor styles | |
| Small space urban homes | Combined console and table set provides coordinated furniture without mismatched styling | |
| Display use for decorative items | Open side shelf and top surfaces support books, art and decorative objects as shown |
EU Market Access Requirements* EN Standards
| EN 312:2010 | Particleboard specifications for load-bearing furniture panel performance requirements | |
|---|---|---|
| EN 13722:2004 | Furniture strength and durability requirements for storage cabinets, applicable to drawer and carcass testing | |
| EN 12521:2015 | Furniture strength, durability and safety requirements for domestic living room tables |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to cabinet and table structural safety | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E0-grade panel material acceptance | |
| GB/T 4897.3-2015 | Particleboard and fiberboard specifications for furniture-grade structural panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to cabinet and table structural safety; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E0-grade panel material acceptance; 3. GB/T 4897.3-2015: Particleboard and fiberboard specifications for furniture-grade structural panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
