Automatic mm / inch conversion · Core engineering specifications
| Overall set dimensions (nested configuration) | 900 x 900 x 500 mm | |
|---|---|---|
| Large coffee table diameter | 900 mm | |
| Large coffee table surface height | 450 mm | |
| Tabletop thickness (both units) | 20 mm | |
| Walnut edge trim width | 20 mm | |
| Curved pull-out drawer extension length | 300 mm | |
| Small side table diameter | 600 mm | |
| Small side table overall height | 500 mm | |
| Rotating door opening width | 280 mm | |
| Internal shelf depth (small unit) | 250 mm | |
| Drawer interior depth (large unit) | 280 mm | |
| Nesting clearance between units when tucked | 10 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total static distributed load for set | 500 kg | |
|---|---|---|
| Large tabletop point load capacity | 100 kg | |
| Drawer slide rated open/close cycles | 10000 cycles | |
| Rotating door pivot rated cycles | 15000 cycles | |
| Tabletop surface heat resistance | 120 °C | |
| Finish abrasion resistance | 2000 cycles | |
| Residential service life | 15 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop (both units) | 20mm white marble-effect sintered stone | |
|---|---|---|
| Tabletop edge trim | Solid walnut hardwood | |
| Large unit cabinet body | 18mm MDF with matte off-white paint finish | |
| Large unit drawer interior | 15mm light walnut veneer engineered wood | |
| Small unit exterior panel | 18mm MDF with saddle brown matte finish | |
| Small unit internal shelves | 15mm dark walnut veneer engineered wood | |
| Drawer hardware | Three-section silent full-extension steel slides | |
| Rotating door hardware | Zinc alloy 360° pivot hinge | |
| Base foot pads | Non-slip 5mm thick felt pads | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Nesting design | Small table tucks partially under large table to reduce footprint when not in use | |
|---|---|---|
| Large table curved drawer | Pull-out curved drawer opens outward for concealed storage of living room items | |
| Small table rotating door | Curved door rotates on central pivot to reveal tiered internal open shelving | |
| Surface protection | Sintered stone top resists scratches, stains and water damage from daily use | |
| Weight distribution | Cylindrical pedestal base evenly distributes load to prevent floor indentation | |
| Multi-use configuration | Small table functions as standalone side table next to seating when un-nested | |
| Soft-close drawer action | Drawer slides include damping to prevent slamming during closure | |
| Internal shelf organization | Two tiered shelves in small unit separate small items for organized storage | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential living room | Placed in front of sofas for serving snacks, drinks and decorative display | |
|---|---|---|
| Small apartment spaces | Nesting function reduces footprint when extra surface space is not required | |
| Lounge and reception areas | Used in casual office lounges or residential reception spaces for guest use | |
| Bedroom side use | Small unit used as a bedside table for lamps, books and personal items | |
| Modern interior schemes | Complements minimalist, light luxury and contemporary walnut and white decor styles | |
| Open-plan living spaces | Separated units create multiple surface points for flexible entertaining layouts |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements for domestic living room tables | |
|---|---|---|
| EN 312:2010 | Performance requirements for particleboard used in furniture construction | |
| EN 71-3:2019 | Migration of certain elements for furniture used in household environments |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to cabinet and structural components | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard/fiberboard requirements for furniture-grade engineered wood used in cabinet bodies | |
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit for wooden furniture components | |
| GB/T 17657-2013 | Test methods for surface finish durability and physical properties of wood-based panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to cabinet and structural components; 2. GB/T 4897.3-2003: Particleboard/fiberboard requirements for furniture-grade engineered wood used in cabinet bodies; 3. GB 18584-2001: Indoor decoration material formaldehyde emission limit for wooden furniture components; 4. GB/T 17657-2013: Test methods for surface finish durability and physical properties of wood-based panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
