Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 800 x 800 x 500 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Lower plinth base height | 60 mm | |
| Upper open shelf internal height | 180 mm | |
| Lower open shelf internal height | 200 mm | |
| Open shelf depth | 380 mm | |
| Closed side panel thickness | 18 mm | |
| Grey shelf edge trim width | 15 mm | |
| Floor clearance under plinth | 10 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total static tabletop load capacity | 34 kg | |
|---|---|---|
| Total product net weight | 25 kg | |
| Recommended maximum number of users | 4 | |
| Surface finish abrasion resistance | 300 cycles | |
| Wood-based panel moisture content | 12% | |
| Warranty period | 365 days | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | 18mm E1-grade engineered wood | |
|---|---|---|
| Tabletop finish | Walnut brown matte thermally fused laminate | |
| Body panels | 16mm matte black engineered wood | |
| Shelf edge trim | Grey PVC edge banding | |
| Plinth base | Matte black engineered wood wrapped base | |
| Internal shelf substrate | 16mm black engineered wood | |
| Assembly hardware | Zinc-plated steel confirmat screws | |
| Surface coating thickness | 0.1mm laminate wear layer | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | Two fixed horizontal open shelves on one side, one solid closed side panel | |
|---|---|---|
| Surface function | Flat level tabletop for placing drinks, decor and reading materials | |
| Placement stability | Full wrapped plinth base for even weight distribution across floor contact area | |
| Access orientation | Single-side shelf access, closed panel hides clutter from adjacent viewing angles | |
| Cleaning compatibility | Smooth non-porous laminate surfaces suitable for wiping with damp cloth | |
| Assembly requirement | Knock-down assembly using included hex key and hardware | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Office reception lounge | Place between armchairs or sofas for guest drink and reading material storage | |
|---|---|---|
| Residential living room | Position adjacent to sectional sofas for everyday snack, drink and media storage | |
| Small office breakout area | Use as side table next to casual seating for employee break items | |
| Waiting area seating zone | Deploy beside waiting chairs for visitor reading materials and beverages | |
| Studio apartment flexible seating | Double as compact side table or extra surface for small living spaces |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements for domestic tables, applicable for performance testing | |
|---|---|---|
| EN 13722:2004 | Surface resistance to cold liquids for furniture finishes, applicable for laminate top performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural acceptance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor air quality compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural acceptance; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor air quality compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
