Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1200 × 600 × 450 mm | |
|---|---|---|
| Overall assembled dimensions | 1200 x 600 x 450 mm | |
| Tabletop thickness | 12 mm | |
| Tabletop corner radius | 30 mm | |
| Frame leg wall thickness | 1.5 mm | |
| Frame crossbar height from floor | 80 mm | |
| Underside floor clearance under frame crossbar | 80 mm | |
| Leg outer footprint width | 1100 mm | |
| Leg outer footprint depth | 520 mm | |
| Frame tube section dimensions | 40 x 20 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net product weight | 28 kg | |
|---|---|---|
| Distributed static tabletop load capacity | 65 kg | |
| Tabletop Mohs scratch hardness | 6 | |
| Tabletop surface stain resistance grade | 5 | |
| Tabletop water absorption rate | 0.2% | |
| Frame powder coating salt spray resistance | 48 hours | |
| Recommended maximum placed item weight for regular use | 30 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop panel | High-gloss dark grey sintered stone with natural brown/white veining | |
|---|---|---|
| Frame construction | Matte black powder-coated carbon steel tube open sled assembly | |
| Tabletop-frame connection hardware | M8 zinc-plated steel bolts with anti-slip rubber gaskets | |
| Foot pads | Adjustable non-marking PE plastic foot pads | |
| Edge treatment | Polished rounded beveled tabletop edges | |
| Frame weld finish | Ground and powder-coated smooth weld joints | |
| Surface finish layer | Anti-fingerprint nano-coating on sintered stone surface | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Structure type | Fixed single-level non-storage open design | |
|---|---|---|
| Leveling adjustment | 4 adjustable foot pads with 10mm vertical adjustment range | |
| Surface performance | Heat-resistant tabletop supports direct placement of 120°C hot drinkware | |
| Cleaning function | Non-porous stain-resistant surface supports wet wipe cleaning without sealant | |
| Assembly requirement | Knock-down assembly requires 8 bolt connections between top and frame | |
| Structural stability | Welded sled base with full-length crossbar prevents wobble on soft carpet | |
| Safety feature | Rounded 30mm corner edges reduce impact injury risk for household use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Primary placement | Positioned directly in front of 3-seater or L-shaped sofas in residential living rooms | |
|---|---|---|
| Secondary commercial use | Lobby seating areas in boutique hotels, modern offices and apartment common areas | |
| Recommended pairing | Matched with light grey fabric sofas, low-pile carpet, and dark wood media consoles | |
| Suitable user group | Households with children, urban apartment dwellers, modern design enthusiasts | |
| Use limitation | Not suitable for outdoor placement, seating, or loads exceeding rated weight |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Furniture mechanical safety standard | EN 12521:2015 | |
|---|---|---|
| Sintered stone panel standard | EN 14411:2016 | |
| Furniture surface emission standard | EN 13986:2004+A1:2015 |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Sintered stone tabletop standard | GB/T 35165 | |
|---|---|---|
| Steel furniture frame standard | GB/T 3324 | |
| Furniture surface durability standard | GB/T 4893.4 |
This product must meet the following technical requirements: 1. Sintered stone tabletop standard: GB/T 35165; 2. Steel furniture frame standard: GB/T 3324; 3. Furniture surface durability standard: GB/T 4893.4; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
