Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint when fully nested | 800 x 800 x 450 mm | |
|---|---|---|
| Large table dimensions | 800 x 800 x 450 mm | |
| Small table dimensions | 600 x 600 x 420 mm | |
| Tabletop thickness | 12 mm | |
| Metal frame tube section | 20 x 20 mm | |
| Metal frame wall thickness | 1.2 mm | |
| Frame understructure height clearance | 400 mm | |
| Nesting overlap depth | 600 mm | |
| Height difference between tables | 30 mm | |
| Floor clearance under frame base | 10 mm | |
| Tabletop edge profile | 1 mm chamfered eased edge | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total set net weight | 30 kg | |
|---|---|---|
| Large table static distributed load capacity | 100 kg | |
| Tabletop surface abrasion resistance | 4000 cycles | |
| Powder coat finish scratch resistance | 2H pencil hardness | |
| Tabletop water absorption rate | 0.02% | |
| Frame rust resistance rating | 48 hours neutral salt spray | |
| Recommended maximum supported weight per table for regular use | 50 kg | |
| Wobble deflection under full rated load | 2 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Large table tabletop | 12mm matte light gray sintered stone, polished non-porous surface | |
|---|---|---|
| Small table tabletop | 12mm matte light gray sintered stone, matching finish to large table | |
| Structural frame | Matte black powder-coated mild steel square tubing, fully welded joints | |
| Frame surface finish | Epoxy-polyester hybrid powder coating, 60 micron dry film thickness | |
| Frame weld joints | TIG welded corner joints, ground smooth before coating | |
| Floor contact pads | 4mm thick non-marking TPE rubber pads on each frame corner | |
| Tabletop bonding | Structural neutral silicone adhesive securing stone top to metal frame | |
| Frame internal cross bracing | Single horizontal steel cross bar per table at lower frame rail | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Nesting operation | Small table slides bi-directionally under large table without tilting, no mechanical locks required | |
|---|---|---|
| Surface use case compatibility | Waterproof non-porous top supports hot drink ware up to 180°C without discoloration | |
| Cleaning access | Open frame design allows full floor access under both tables for vacuuming and mopping | |
| Layout flexibility | Tables can be separated for use as independent side tables or arranged in stepped staggered configuration | |
| Mobility for reconfiguration | Each table can be lifted and repositioned by two adults with no disassembly required | |
| Load distribution | Welded frame distributes weight evenly across four corner support points | |
| Scratch protection | Rubber floor pads prevent frame contact with hard flooring and low-pile rugs when moving units | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Primary residential use case | Modern minimalist, industrial or Scandinavian style living rooms placed in front of sofas | |
|---|---|---|
| Small space layout suitability | Apartments and compact open-plan living areas where flexible space saving furniture is required | |
| Commercial space use case | Office reception areas, lounge waiting zones or studio break rooms | |
| Functional surface use | Holding beverages, decor items, reading materials or laptop for casual seated use | |
| Recommended complementary furniture | Low-profile fabric or leather sofas with 450 mm seat height, low-pile area rugs | |
| Surface maintenance suitability | High-traffic living areas where easy-to-clean, stain-resistant surfaces are required |
EU Market Access Requirements* EN Standards
| Furniture stability test | EN 12521:2015 | |
|---|---|---|
| Surface resistance to cold liquids | EN 12720:2013 |
Standards applicable to China-market projects
| Tabletop material safety | GB 6566Class A | |
|---|---|---|
| Metal furniture structural safety | GB/T 3324 |
This product must meet the following technical requirements: 1. Tabletop material safety: GB 6566Class A; 2. Metal furniture structural safety: GB/T 3324; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
