Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 860 × 860 × 460 mm | |
|---|---|---|
| Overall set footprint (nested) | 860 x 860 x 460 mm | |
| Larger table diameter | 860 mm | |
| Larger table height | 460 mm | |
| Larger table top thickness | 12 mm | |
| Smaller table diameter | 510 mm | |
| Smaller table height | 410 mm | |
| Smaller table top thickness | 12 mm | |
| Frame vertical leg cross-section | 30 x 30 mm | |
| Frame lower ring diameter (larger table) | 760 mm | |
| Frame lower ring diameter (smaller table) | 450 mm | |
| Metal frame wall thickness | 1.2 mm | |
| Floor clearance under larger table | 430 mm | |
| Top edge trim width | 15 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Larger table distributed static load capacity | 50 kg | |
|---|---|---|
| Frame static load rating | 80 kg | |
| Set total net weight | 26 kg | |
| Top surface scratch resistance | 3000 abrasion cycles | |
| Top surface stain resistance | Household liquid repellent | |
| Frame finish scratch resistance | 1000 abrasion cycles | |
| Recommended maximum number of users for adjacent seating | 4 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Larger table top | 12mm polished white sintered stone, gold metal edge trim | |
|---|---|---|
| Smaller table top | 12mm polished black sintered stone, thin brass inlay line across surface | |
| Frame vertical legs | Brushed gold finished carbon steel, 30x30mm square section | |
| Frame lower support ring | Brushed gold finished carbon steel, continuous circular welded construction | |
| Top metal edge trim | Stamped gold plated stainless steel, 15mm width | |
| Small table surface inlay | Solid brass decorative strip, flush-set into black top surface | |
| Frame weld joints | Full penetration welded steel joints, ground smooth for finish | |
| Floor contact pads | Non-slip PE plastic foot pads, attached to bottom of ring base | |
| Frame surface finish | High-temperature baked gold paint, brushed texture | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Nesting storage function | Smaller table slides partially under larger table to reduce footprint | |
|---|---|---|
| Surface use function | Flat polished tops support drinks, reading materials, and decorative items | |
| Independent use function | Both tables can be separated and used as standalone side or accent tables | |
| Floor protection function | Underside foot pads prevent scratches to hard flooring and rugs | |
| Cleaning function | Non-porous smooth top surfaces wipe clean with a damp cloth | |
| Assembly requirement | Frame attaches to top with included hardware, no special tools needed | |
| Weight distribution | Circular ring base spreads load evenly to prevent tipping on soft rugs | |
| Color coordination | Two-tone black/white tops match neutral and luxury living room decor schemes | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Primary living room placement | Positioned in front of 3-seat sofas for serving drinks and decor | |
|---|---|---|
| Small apartment use | Nested configuration saves floor space in compact living areas | |
| Open concept lounge use | Separated tables provide extra surface space for gatherings | |
| Model home/staging use | Luxury two-tone gold finish fits contemporary upscale interior schemes | |
| Balcony/sunroom use | Compact size fits small lounge seating areas in covered outdoor spaces | |
| Home office lounge use | Placed beside lounge seating in office break areas for refreshments | |
| Recommended pairing | Matches upholstered velvet or linen sofas with gold metal accent furniture |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Strength, durability and safety requirements for domestic tables | |
|---|---|---|
| EN 15187:2006 | Assessment of surface resistance to dry heat for furniture surfaces | |
| EN 1022:2018 | Stability testing for domestic seating and tables |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to top panel performance | |
|---|---|---|
| GB/T 4893.4-2013 | Surface wear resistance test for furniture surfaces, applicable to top finish | |
| GB/T 1732-2020 | Impact resistance test for paint films, applicable to metal frame finish | |
| GB 18584-2001 | Limit of harmful substances for wooden furniture, applicable for indoor air safety |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to top panel performance; 2. GB/T 4893.4-2013: Surface wear resistance test for furniture surfaces, applicable to top finish; 3. GB/T 1732-2020: Impact resistance test for paint films, applicable to metal frame finish; 4. GB 18584-2001: Limit of harmful substances for wooden furniture, applicable for indoor air safety; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
