Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 900 × 900 × 380 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total set weight | 38 kg | |
|---|---|---|
| Large tabletop static load | 50 kg | |
| Small tabletop static load | 30 kg | |
| Table edge impact resistance | 200 N | |
| Surface abrasion resistance | 4000 cycles | |
| Recommended maximum weight on nested set | 80 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 12mm tempered glass | |
|---|---|---|
| Tabletop inlay | Resin and veneer art pattern | |
| Edge banding | Matte black painted MDF | |
| Support legs | Black stained solid ash wood | |
| Bottom foot pads | 5mm thick anti-slip rubber | |
| Finish coating | Matte polyurethane wood finish | |
| Glass surface coating | Anti-scratch UV coating | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Nesting function | Small table slides partially under large table to save space | |
|---|---|---|
| Leveling adjustment | 10 mm height adjustment on foot pads | |
| Surface cleaning | Smooth non-porous top allows wet wiping without water damage | |
| Multi-level serving | Dual height surfaces separate display and serving items | |
| Fixed structure | Legs are permanently attached to tabletop frame for rigidity | |
| Decorative display | Patterned top doubles as a visual accent piece | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Living room placement | Positioned in front of 3-seat or L-shaped sofas for beverage and decor placement | |
|---|---|---|
| Lounge and reception areas | Used in boutique hotel lounges or office reception zones for artistic accent | |
| Small apartment use | Nesting design saves floor space when full surface area is not required | |
| Open-plan lounge zones | Separated tables create flexible surface placement for entertaining | |
| Contemporary interior schemes | Matches modern, wabi-sabi and art-inspired interior design styles | |
| Low-height display use | Small table holds sculptural decor and reading materials next to seating |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
