Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1200 × 700 × 550 mm | |
|---|---|---|
| Tabletop thickness | 18 mm | |
| Tabletop edge radius | 30 mm | |
| Lower shelf depth | 500 mm | |
| Lower shelf vertical clearance from floor | 180 mm | |
| Left enclosed cabinet width | 400 mm | |
| Frame tube diameter | 30 mm | |
| Leg span at floor (right side) | 350 mm | |
| Lower shelf vertical clearance under tabletop | 280 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Tabletop static load capacity | 100 kg | |
|---|---|---|
| Net product weight | 55 kg | |
| Seating capacity for tea service | 4 people | |
| Tabletop surface heat resistance | 180 °C | |
| Floor clearance under left cabinet | 10 mm | |
| Frame finish abrasion resistance | 2000 cycles | |
| Tabletop surface dry heat resistance | 180 °C | |
| Tabletop stain resistance rating | Grade 5 | |
| Frame joint static load failure threshold | 150 kg | |
| Floor protection load per foot | 20 kg |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop | 18mm grey veined polished sintered stone | |
|---|---|---|
| Frame and legs | Matte black powder-coated carbon steel tube | |
| Left side panel (vertical ribbed) | Matte black fluted MDF panel with PVC finish | |
| Left front panel (smooth) | Matte black smooth MDF panel with PU coating | |
| Lower storage shelf | Matte black powder-coated steel sheet | |
| Edge banding | Light grey PVC edge trim | |
| Leveler feet | Nylon non-slip adjustable feet | |
| Frame joinery | Welded metal joints with powder coat finish | |
| Left side ribbed panel | 15mm thick matte black fluted MDF panel with PVC laminated finish | |
| Left front smooth panel | 15mm thick matte black smooth MDF panel with PU spray finish | |
| Tabletop edge banding | 1mm thick light grey PVC edge trim | |
| Tabletop mounting connectors | M6 x 20mm zinc-plated steel machine screws with rubber anti-slip washers |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Open lower shelf storage | Full-width open shelf under right table section provides accessible storage for tea accessories, reading materials and remote controls | |
|---|---|---|
| Enclosed left support cabinet | Fully enclosed box-style left support provides structural stability and hidden internal storage space | |
| Integrated tea service surface | Heat-resistant smooth sintered stone top supports direct placement of boiling water teapots and tea ware without additional coasters | |
| Stable angled leg support | Dual parallel-bar angled right leg distributes tabletop weight across a wide floor footprint to eliminate wobble during use | |
| Floor protection system | Adjustable nylon feet at all base contact points prevent scratching hard flooring and compensate for 10mm of uneven floor height | |
| Rounded edge safety design | 30mm radius rounded corners on tabletop and frame eliminate sharp impact points for household use with children or high-traffic spaces | |
| Enclosed left support storage | 400mm wide x 660mm deep fully enclosed box-style left support provides 480mm internal height hidden storage space, while acting as primary structural support for the left tabletop end | |
| Heat-resistant tea service surface | Non-porous polished sintered stone top supports direct placement of 180°C hot teapots and boiling water tea ware without coasters, with a stain-resistant surface that wipes clean of tea and water spills in 1 pass | |
| Floor protection and leveling system | 4 adjustable nylon feet at all base contact points prevent scratching hardwood, tile and vinyl flooring, and compensate for 10mm of uneven floor height to keep the tabletop perfectly level | |
| Anti-slip tabletop mounting | Rubber-washer secured tabletop connection prevents lateral shifting of the stone top during use, eliminating rattling when placing or moving heavy tea sets | |
| Robot vacuum compatible clearance | 180mm minimum floor clearance under the lower shelf and frame allows passage of most standard 100mm height residential robot vacuums for cleaning under the table without moving it | |
| Scratch-resistant frame finish | 60μm thick matte powder coat finish resists scuffs and scratches from daily contact with shoes, cleaning tools and stored items, retaining finish appearance over long-term use |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Number of shipping packages | 1 | |
|---|---|---|
| Shipping carton dimensions | 1280 x 780 x 620 mm | |
| Gross shipping weight | 62 kg | |
| Shipping volume per unit | 0.62 CBM | |
| Assembly time | 20 minutes | |
| 20ft GP container loading quantity | 45 units | |
| 40ft HQ container loading quantity | 110 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room | Placed in front of sofas in modern home living rooms as a central coffee and tea service surface | |
|---|---|---|
| Office reception area | Installed in corporate reception lounges and executive office breakout areas to serve guests tea and beverages | |
| Tea room and casual lounge | Used in dedicated tea tasting rooms and casual hospitality spaces for dedicated tea preparation and service | |
| Small apartment open plan space | Suitable for compact urban apartments with integrated lower storage reducing need for additional side furniture | |
| Balcony casual seating area | Placed on covered residential balconies paired with low leisure chairs for outdoor tea and coffee service | |
| Covered balcony casual seating area | Placed on covered residential balconies paired with 450mm seat height low leisure chairs for semi-outdoor tea and coffee service; powder coated steel frame and sealed MDF panels resist mild humidity from covered outdoor conditions without rust or warping | |
| Hotel guest room lounge area | Installed in suite lounge areas of mid-range to high-end boutique hotels paired with upholstered armchairs for guest beverage service; durable scratch-resistant finish withstands frequent commercial cleaning and guest use |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Furniture stability recommendation | EN 15372:2008 Furniture - Strength, durability and safety - Requirements for non-domestic tables | |
|---|---|---|
| Surface heat resistance recommendation | EN 12721:2013 Furniture - Test methods for surfaces - Assessment of resistance to dry heat | |
| Domestic table safety and durability | EN 12521:2015 Furniture - Strength, durability and safety - Requirements for domestic tables | |
| Surface dry heat resistance | EN 12721:2013 Furniture - Test methods for surfaces - Assessment of resistance to dry heat | |
| Surface stain resistance | EN 12720:2009 Furniture - Test methods for surfaces - Assessment of resistance to cold liquids | |
| Formaldehyde emission for panel components | EN 13986:2004 Wood-based panels for use in construction - Characteristics, evaluation of conformity and marking |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Tabletop surface performance recommendation | GB/T 3324General technical requirements for wooden furniture | |
|---|---|---|
| Metal frame coating recommendation | GB/T 2020Determination of impact resistance of paint films | |
| Formaldehyde emission recommendation | GB 18584Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | |
| General furniture technical requirement | GB/T 3324General technical requirements for wooden furniture | |
| Metal coating impact resistance | GB/T 2020Determination of impact resistance of paint films | |
| Formaldehyde emission limit | GB 18584Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture |
This product must meet the following technical requirements: 1. Tabletop surface performance recommendation: GB/T 3324General technical requirements for wooden furniture; 2. Metal frame coating recommendation: GB/T 2020Determination of impact resistance of paint films; 3. Formaldehyde emission recommendation: GB 18584Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture; 4. General furniture technical requirement: GB/T 3324General technical requirements for wooden furniture; 5. Metal coating impact resistance: GB/T 2020Determination of impact resistance of paint films; 6. Formaldehyde emission limit: GB 18584Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
