Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 600 x 450 mm | |
|---|---|---|
| Top glass thickness | 12 mm | |
| Lower shelf glass thickness | 10 mm | |
| Stainless steel square tube leg section | 50 x 50 mm | |
| Clearance between top and lower shelf | 280 mm | |
| Lower shelf dimensions | 1100 x 500 mm | |
| Floor clearance under lower shelf | 100 mm | |
| Frame tube wall thickness | 1.2 mm | |
| Glass overhang past frame perimeter | 10 mm | |
| Leg base contact pad diameter | 30 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Product net weight | 38 kg | |
|---|---|---|
| Top surface static load capacity | 50 kg | |
| Recommended maximum number of users | 4 | |
| Tempered glass impact resistance | 1 kg steel ball drop from 1000 mm height | |
| Frame joint static load strength | 100 kg vertical load applied per leg without permanent deformation | |
| Adjustable glide vertical adjustment range | 10 mm | |
| Finish abrasion resistance | 1000 rubbing cycles with dry cotton cloth without visible polish wear or tarnish | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop surface | Black tempered glass with high-gloss reflective finish | |
|---|---|---|
| Lower storage shelf | Black tempered glass with matching high-gloss finish | |
| Support frame and legs | Polished 201 stainless steel square tubing with mirror chrome finish | |
| Glass edge treatment | Flat polished edge with micro-bevel | |
| Frame welds | TIG welded joints with polished seamless finish | |
| Foot pads | Non-marking PE adjustable glides | |
| Glass to frame bonding | Structural silicone adhesive with hidden rubber buffer strips | |
| Surface coating on steel | Electroplated mirror polish with clear anti-tarnish lacquer | |
| Glass to frame connection | Structural silicone adhesive with 2mm hidden EPDM rubber buffer strips | |
| Steel surface protection | Electroplated mirror polish with 10μm clear anti-tarnish lacquer | |
| Assembly hardware | M8 zinc-plated steel hex bolts with matching lock washers | |
| Frame cross bracing | 25x25mm polished stainless steel square tube crossbars welded between leg sections |
Adjustment / rotation / tilt / mobility / storage features
| Two-tier open storage design | Open upper tabletop for beverage service and display, lower open shelf for book, magazine and decor storage | |
|---|---|---|
| Easy-clean glass surfaces | Non-porous glossy glass surfaces that wipe clean with standard glass cleaning products, no special surface treatment required | |
| Adjustable floor glides | Rotating PE foot pads at each leg base to adjust for uneven floor surfaces and prevent scratching hard flooring | |
| Stable open-frame structure | Four interconnected U-shaped leg assemblies linked by perimeter crossbars under both glass tiers to eliminate wobble | |
| Scratch-resistant top surface | Tempered glass surface resists minor scuffs from mugs, books and everyday household objects | |
| Assembly requirement | Knock-down assembly with 8 bolted connections between leg sections and crossbars, no specialist tools required | |
| Knock-down assembly | Flat-packed configuration with 8 M8 bolted connections between leg sections and crossbars, assembly completed with included hex key in 30 minutes by 2 people | |
| Anti-tarnish frame finish | Mirror polished stainless steel frame with clear lacquer coating prevents fingerprint marks and surface corrosion under normal indoor use for 3 years | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 2 | |
|---|---|---|
| Main carton (frame components) dimensions | 1280 x 680 x 120 mm | |
| Glass package dimensions | 1250 x 650 x 80 mm | |
| Total shipping gross weight | 45 kg | |
| Total shipping volume (CBM) | 0.12 | |
| On-site assembly time | 30 minutes | |
| 20ft GP container loading quantity | 210 units | |
| 40ft HQ container loading quantity | 520 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Office reception areas | Fits in front of reception sofas in lobbies and meeting waiting areas to hold beverages, reading materials and decor for visitors | |
|---|---|---|
| Modern residential living rooms | Serves as a central coffee table in minimalist, contemporary or urban style living spaces placed in front of 3-seater sofas | |
| Executive lounge spaces | Suitable for placement in executive break areas or private office lounge zones for casual meeting and refreshment service | |
| Small apartment living spaces | Open-frame design creates a visually lightweight profile that does not overwhelm compact living areas, while providing double the storage surface of single-tier tables | |
| Showroom and display spaces | Can be used as a display plinth for retail or showroom settings to showcase decorative objects and merchandise | |
| Hotel guest sitting areas | Appropriate for placement in hotel suite living areas or public lounge seating zones, with scratch-resistant surfaces that withstand frequent guest use |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements for domestic tables, applicable for structural load testing | |
|---|---|---|
| EN 12150-1:2015 | Safety requirements for thermally toughened soda lime silicate glass used in furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural stability and finish performance verification | |
|---|---|---|
| GB 15763.2-2005 | Safety requirements for tempered glass used in furniture construction, specifying impact resistance and fragmentation properties | |
| GB/T 24821-2009 | Performance requirements for metal furniture frames, covering load capacity, weld strength and corrosion resistance | |
| GB/T 17657-2013 | Test methods for surface finish durability, applicable for verifying abrasion and tarnish resistance of metal and glass surfaces |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural stability and finish performance verification; 2. GB 15763.2-2005: Safety requirements for tempered glass used in furniture construction, specifying impact resistance and fragmentation properties; 3. GB/T 24821-2009: Performance requirements for metal furniture frames, covering load capacity, weld strength and corrosion resistance; 4. GB/T 17657-2013: Test methods for surface finish durability, applicable for verifying abrasion and tarnish resistance of metal and glass surfaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
