Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1500 x 800 x 450 mm | |
|---|---|---|
| Tabletop thickness | 18 mm | |
| Leg section size | 50 x 30 mm | |
| Metal frame wall thickness | 2 mm | |
| Lower stretcher clearance from floor | 120 mm | |
| Tabletop corner radius | 30 mm | |
| Under-table knee clearance height | 380 mm | |
| Leg footprint outer length | 1420 mm | |
| Leg footprint outer width | 720 mm | |
| Tabletop edge overhang | 40 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Distributed static top load capacity | 70 kg | |
|---|---|---|
| Product net weight | 45 kg | |
| Frame anti-deformation static load | 150 kg | |
| Surface scratch resistance rating | Grade 2 | |
| Surface heat resistance temperature | 180 °C | |
| Recommended maximum placed object weight | 25 kg | |
| Leveling adjustment range per foot | 10 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop panel | 18mm dark sintered stone with matte polished smooth surface | |
|---|---|---|
| Edge treatment | Machine-polished rounded softened edges for anti-bump safety | |
| Support legs | Matte black powder-coated carbon steel tube with welded joints | |
| Perimeter stretcher frame | Continuous welded carbon steel tube connecting all four legs for rigidity | |
| Frame surface finish | 60um thick matte black baked powder coat for scratch and rust resistance | |
| Tabletop to frame connectors | M8 carbon steel bolts with anti-loosening washers, 8 connection points total | |
| Floor contact pads | 8mm thick non-slip PVC pads under each leg base to protect flooring | |
| Frame joint construction | Full penetration welded joints with ground smooth welds for seamless appearance | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Structure type | Fixed rigid non-adjustable open frame design with no moving parts | |
|---|---|---|
| Storage configuration | No enclosed drawers, shelves, or compartments for unobstructed under-table space | |
| Mobility feature | No integrated casters, designed for static center-of-living-room placement | |
| Leveling function | Adjustable hidden foot pads at each leg base to correct minor floor unevenness | |
| Surface use case | Smooth non-porous tabletop supports placement of books, decor, and drinkware with easy wiping | |
| Stability feature | Continuous perimeter stretcher eliminates frame wobble during regular use | |
| Cleaning compatibility | Matte non-porous finishes support dry or damp cloth cleaning without special treatment | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Contemporary residential living room, positioned centrally in front of sofa | |
|---|---|---|
| Secondary application space | Modern office reception lounge or waiting area for guest refreshment placement | |
| Recommended matching seating | Low-profile sofas and armchairs with 450 mm seat height for ergonomic access | |
| Style compatibility | Modern minimalist, Italian light luxury, industrial, and dark-toned interior design schemes | |
| Surface use suitability | Display of decorative objects, reading materials, and casual beverage service during daily use | |
| Space size recommendation | Living areas with minimum 3m x 3m open floor space to accommodate proportional placement |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture strength, durability and safety for domestic tables | |
|---|---|---|
| EN 15187:2006 | Assessment of surface resistance to dry heat for furniture finishes |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural safety verification | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable if substrate is wood composite | |
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural safety verification; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable if substrate is wood composite; 3. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
