Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (W x D x H) | 1300 x 700 x 550 mm | |
|---|---|---|
| Tabletop thickness | 12 mm | |
| Frame vertical bar width | 25 mm | |
| Lower storage shelf height from floor | 100 mm | |
| Kettle cutout recessed dimensions | 370 x 250 mm | |
| Tea tray dimensions | 650 x 400 mm | |
| Vertical bar spacing on long sides | 120 mm | |
| Frame tube wall thickness | 1.2 mm | |
| Clear legroom height under tabletop front edge | 528 mm | |
| Lower shelf usable depth | 640 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Net weight | 42 kg | |
|---|---|---|
| Tabletop static load capacity | 150 kg | |
| Suitable number of users | 4 | |
| Tabletop impact resistance | 6 mm steel ball drop 300 mm no crack | |
| Tabletop surface abrasion resistance | Grade 4, 6000 abrasion cycles | |
| Frame weld static joint strength | 1000 N per joint | |
| Net product weight | 42 kg | |
| Standard seating capacity for tea service | 4 users | |
| Frame welded joint static strength | 1000 N per joint | |
| Adjustable foot uneven floor compensation | 10 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop slab | 12mm dark grey matte sintered stone, polished matte finish, anti-scratch and heat-resistant to 180°C | |
|---|---|---|
| Support frame | 1.2mm thick carbon steel square tube, matte black electrostatic powder coating, welded construction | |
| Cross bracing | 20mm diameter round carbon steel tube with matching black powder coat, X-brace under lower shelf for torsional rigidity | |
| Lower storage shelf panel | 0.8mm thick textured black powder-coated steel sheet, supported by frame perimeter | |
| Recessed tea tray | 8mm thick clear tempered glass, textured drainage surface with integrated drain outlet | |
| Kettle cutout reinforcement | 1.5mm thick galvanized steel support plate under tabletop cutout, supports electric tea boiler weight | |
| Frame foot pads | 5mm thick non-slip PVC adjustable feet, 20mm diameter, compensates for 5mm floor unevenness | |
| Under-table cross bracing | 20mm diameter round carbon steel tube with matching black powder coat, curved X-brace under lower shelf for torsional rigidity | |
| Lower storage shelf support | 0.8mm thick textured black powder-coated steel sheet, perimeter welded to frame rails | |
| Drainage fitting | 12mm diameter food-grade PVC drain hose, routed inside frame cavity to connect tray outlet to waste bin | |
| Assembly fasteners | M8 zinc-plated steel hex bolts with lock washers, 16 total fasteners for frame and tabletop mounting | |
| Cutout edge trim | 2mm thick black silicone edge seal around kettle cutout, prevents water seepage under tabletop |
Adjustment / rotation / tilt / mobility / storage features
| Integrated tea brewing station | Recessed tabletop cutout accommodates standard fully automatic electric tea boiler with water pump, positioned for left-side operation | |
|---|---|---|
| Built-in tea drainage system | Tempered glass tea tray connects to hidden drain hose routed through frame to waste bin placed on lower shelf | |
| Bulk water storage | Open lower shelf accommodates standard 18.9L bottled water for the integrated tea pump, with 320mm clearance for bottle placement | |
| Waste bin storage | Lower shelf provides dedicated space for 10L tea waste bucket positioned directly under drain outlet | |
| Fixed height work surface | 550mm table height optimized for seated use on standard sofas or lounge chairs for casual tea drinking | |
| Heat-resistant work surface | Sintered stone top supports direct placement of hot teapots and boiling kettles up to 180°C without surface damage | |
| Anti-scratch tabletop surface | Matte sintered stone finish resists scratches from teacups, tea trays and daily use objects without visible wear over standard use | |
| Open side access | Vertical slatted frame design provides unobstructed leg access from all four sides for seated users | |
| Leveling adjustment | Threaded PVC feet at each frame leg adjust 10mm total height to compensate for uneven hard floors, eliminating table wobble | |
| Open access design | Vertical slatted frame provides unobstructed leg access from all four sides for seated users, no solid panels blocking knee space | |
| Cable routing clearance | Open frame design allows power cord for electric tea boiler to be routed down frame legs to floor outlets without visible cord clutter | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 1 | |
|---|---|---|
| Shipping carton dimensions | 1380 x 780 x 130 mm | |
| Gross shipping weight | 48 kg | |
| Shipping volume per unit | 0.14 CBM | |
| Required assembly time | 35 minutes | |
| 20ft GP container loading quantity | 190 units | |
| 40ft HQ container loading quantity | 490 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm |
Recommended spaces / users / usage modes
| Living room lounge tea area | Suitable for placement in front of 3-seat sofas in residential living rooms for casual tea service and daily use | |
|---|---|---|
| Office reception lounge | Suitable for corporate reception areas and executive lounge spaces for serving tea to visiting guests | |
| Tea house and casual cafe seating | Suitable for small private booths in tea houses or boutique cafes for dedicated tea service | |
| Balcony leisure space | Suitable for enclosed balcony or sunroom casual seating areas for small group tea gatherings | |
| Recommended matching seating | Pairs with standard height lounge chairs, sofas with 450 mm seat height for comfortable seated use | |
| Residential living room tea area | Suitable for placement in front of 3-seat sofas in residential living rooms for daily casual tea service and snack placement | |
| Corporate office reception lounge | Suitable for executive lounge and guest reception areas for serving tea to visiting clients | |
| Tea house private booth seating | Suitable for small private rooms in tea houses or boutique cafes for dedicated kung fu tea service |
EU Market Access Requirements* EN Standards
| Table mechanical safety | EN 15372:2016 Furniture - Strength, durability and safety - Requirements for non-domestic tables, applicable for light commercial office lounge use | |
|---|---|---|
| Surface material fire performance | EN 13501:2018 Fire classification of construction products and building elements, applicable for tabletop reaction to fire classification | |
| Table mechanical safety and durability | EN 15372:2016 Furniture - Strength, durability and safety - Requirements for non-domestic tables, applicable for light commercial office lounge use | |
| Surface reaction to fire | EN 13501:2018 Fire classification of construction products and building elements, applicable for tabletop fire performance classification | |
| Formaldehyde and VOC emissions | EN 16516:2017 Construction products - Assessment of release of dangerous substances - Determination of emissions into indoor air, applicable for coating and adhesive VOC limits |
Standards applicable to China-market projects
| Table structural stability | GB/T 3324General technical requirements for wooden furniture, applicable for structural stability and safety acceptance inspection for fixed tables | |
|---|---|---|
| Sintered stone surface safety | GB 6566Radionuclide limits for building materials, applicable for decorative stone surface radiological safety testing | |
| Powder coating environmental compliance | GB 18584Indoor decorating and refurbishing materials - Limit of harmful substances of wood furniture, applicable for coating heavy metal and VOC limits | |
| Stone surface radiological safety | GB 6566Radionuclide limits for building materials, applicable for sintered stone surface radiological safety testing | |
| Coating environmental compliance | GB 18584Indoor decorating and refurbishing materials - Limit of harmful substances for furniture, applicable for powder coating heavy metal and VOC content limits | |
| Tempered glass safety | GB 15763.2Safety glazing materials in building - Part 2: Tempered glass, applicable for tempered glass tea tray impact and breakage safety |
This product must meet the following technical requirements: 1. Table structural stability: GB/T 3324General technical requirements for wooden furniture, applicable for structural stability and safety acceptance inspection for fixed tables; 2. Sintered stone surface safety: GB 6566Radionuclide limits for building materials, applicable for decorative stone surface radiological safety testing; 3. Powder coating environmental compliance: GB 18584Indoor decorating and refurbishing materials - Limit of harmful substances of wood furniture, applicable for coating heavy metal and VOC limits; 4. Stone surface radiological safety: GB 6566Radionuclide limits for building materials, applicable for sintered stone surface radiological safety testing; 5. Coating environmental compliance: GB 18584Indoor decorating and refurbishing materials - Limit of harmful substances for furniture, applicable for powder coating heavy metal and VOC content limits; 6. Tempered glass safety: GB 15763.2Safety glazing materials in building - Part 2: Tempered glass, applicable for tempered glass tea tray impact and breakage safety; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
