Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 500 x 500 x 560 mm | |
|---|---|---|
| Tabletop diameter | 500 mm | |
| Tabletop thickness | 32 mm | |
| Base floor contact diameter | 305 mm | |
| Base top attachment diameter | 220 mm | |
| Carry cutout height | 300 mm | |
| Carry cutout width | 120 mm | |
| Tabletop edge overhang | 30 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Net product weight | 9 kg | |
|---|---|---|
| Tabletop static load capacity | 45 kg | |
| Recommended maximum placed item weight | 25 kg | |
| Tilt stability angle | 15 degrees | |
| Surface scratch resistance rating | 2H pencil hardness | |
| Color option count | 2 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | 18 mm thick MDF engineered wood | |
|---|---|---|
| Tabletop surface finish | Matte white thermofused laminate | |
| Tabletop edge treatment | Rounded PVC edge banding | |
| Pedestal base structure | Hollow formed MDF or powder-coated steel construction | |
| Base surface finish | Matte black baked paint coating | |
| Carry cutout edge finish | Sanded and painted rounded edges | |
| Floor contact pad | 3 mm thick non-slip EVA foam pad | |
| Top-to-base connection | M8 steel cross-dowels and machine screws | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Integrated carry handle | Rounded rectangular cutout in pedestal allows one-handed lifting | |
|---|---|---|
| Surface use function | Flat round top supports drinks, small decor, table lamps or books | |
| Knockdown assembly | Tabletop attaches to base via included hardware, no special tools required | |
| Stable floor contact | Wide tapered base distributes weight evenly on hard floors and low-pile carpet | |
| Easy surface maintenance | Non-porous matte finish wipes clean with a soft damp cloth | |
| Compact footprint | 305 mm diameter base fits in tight small-space gaps between seating | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Packaging protection | 5 mm thick EPS foam corners and poly bag wrap | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Living room end table placement | Position next to sofas or armchairs to hold drinks, remotes and small decor | |
|---|---|---|
| Bedroom nightstand use | Place beside beds to hold table lamps, phones and bedtime reading items | |
| Small space studio apartment use | Portable design allows easy repositioning for temporary surface needs | |
| Office lounge or waiting area use | Deploy in reception seating zones to hold refreshments for guests | |
| Balcony casual surface use | Suitable for covered outdoor balcony placement with sealed surfaces |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
