Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 1400 x 700 x 450 mm | |
|---|---|---|
| Tabletop material thickness | 15 mm | |
| Floor contact plinth base height | 0 mm | |
| Seam width between modules | 2 mm | |
| Table corner radius | 2 mm | |
| Under-table floor clearance | 0 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total net weight per set | 42 kg | |
|---|---|---|
| Distributed tabletop static load capacity | 72 kg | |
| Surface impact resistance | ≥6 J | |
| Surface water resistance rating | Grade 0 | |
| Finish abrasion resistance | 2000 cycles | |
| Recommended maximum placed object height | 400 mm | |
| Standard warranty period | 2 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Light grey/white block tabletop | 15mm matte sintered stone with marble pattern | |
|---|---|---|
| Black block tabletop | Engineered wood with matte black open-grain wood veneer | |
| Light grey/white block vertical sides | Matte sintered stone with matching marble pattern | |
| Black block vertical sides | Engineered wood with matching matte black wood veneer | |
| Internal block core structure | E0 grade high-density particleboard frame | |
| Module joint connectors | Zinc-plated steel cam lock connectors | |
| Bottom floor protection pads | 3mm thick non-slip felt pads | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Modular arrangement flexibility | Two equal blocks can be placed side-by-side, separated, or offset | |
|---|---|---|
| Tabletop surface function | Flat even surface for placing beverages, decor, and serving items for lounge seating | |
| No moving components | No drawers, lift mechanisms, casters, or hinged panels visible | |
| Surface spill resistance | Sealed non-porous top prevents liquid penetration into block core | |
| Floor protection function | Felt bottom pads prevent scuffs and scratches on carpet or hard flooring | |
| Single square block dimensions | 700 x 700 x 450 mm | |
| Block body wall thickness | 18 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Living room lounge area | Placed in front of sofas or sectionals for beverage and decor display, appropriate low 450mm height | |
|---|---|---|
| Minimalist modern interior schemes | Suits monochrome, wabi-sabi, or contemporary styled spaces with clean geometric lines | |
| Residential open-plan seating zones | Two modules can be adjusted for flexible layout in apartment or open living spaces | |
| Small office reception waiting areas | Suitable for placing magazines and visitor refreshments in low-traffic reception spaces | |
| Low-profile lounge configuration | Pairs with floor cushions or low modular seating for casual relaxed lounge layouts |
EU Market Access Requirements* EN Standards
| EN 15372:2016 | Furniture safety, strength and durability for domestic tables, applicable for structural testing | |
|---|---|---|
| EN 12720:2013 | Furniture surface resistance to cold liquids, applicable to tabletop finish acceptance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to product structural integrity | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, applicable to core panel material acceptance | |
| GB/T 4893.8-2013 | Surface furniture test for abrasion resistance, applicable to finish durability acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to product structural integrity; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, applicable to core panel material acceptance; 3. GB/T 4893.8-2013: Surface furniture test for abrasion resistance, applicable to finish durability acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
