Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 800 x 800 x 450 mm | |
|---|---|---|
| tabletop diameter | 800 mm | |
| tabletop thickness | 25 mm | |
| base floor footprint diameter | 550 mm | |
| metal frame rod diameter | 12 mm | |
| bottom horizontal support ring diameter | 520 mm | |
| floor clearance under support ring | 60 mm | |
| undertop knee clearance height | 425 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| net product weight | 18 kg | |
|---|---|---|
| distributed static tabletop load capacity | 120 kg | |
| frame static load rating | 300 kg | |
| recommended maximum concentrated point load | 30 kg | |
| adjustable foot leveling range | 10 mm | |
| surface wipe-clean durability rating | 10000 cleaning cycles | |
| powder coat finish abrasion resistance | Grade 2 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| tabletop substrate | 18mm thick MDF core | |
|---|---|---|
| tabletop surface finish | White matte laminate veneer | |
| frame construction material | Powder-coated carbon steel rod | |
| frame bracing design | Triangulated cross-braced open frame | |
| frame surface finish | Matte black electrostatic powder coating | |
| floor contact components | Injection-molded non-slip plastic foot pads | |
| fastener hardware | Zinc-plated steel bolts and barrel nuts | |
| frame joint connection | Precision welded joints at all rod intersections | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| assembly requirement | Flat-pack assembly with included hex key and hardware | |
|---|---|---|
| floor protection function | Plastic foot pads prevent scratching hard flooring surfaces | |
| leveling adjustment | Rotating foot pads adjust to compensate for uneven floor surfaces | |
| surface use case | Smooth non-porous top supports drinkware, books, and decorative items | |
| structural stability feature | Triangulated bracing eliminates frame wobble during regular use | |
| lightweight mobility feature | Open hollow wireframe design allows easy repositioning between room layouts | |
| storage clearance feature | Fully open base allows under-table storage of flat items like magazines or floor cushions | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| primary residential use case | Center placement in living rooms in front of sofas for drink and decor placement | |
|---|---|---|
| secondary use case | Lounge or reception area occasional table for waiting spaces | |
| interior style compatibility | Suits minimalist, industrial, Scandinavian, and contemporary decor schemes | |
| space size suitability | Ideal for small to medium sized living areas, compact apartment layouts | |
| floor surface compatibility | Suitable for use on hardwood, tile, laminate, and low-pile carpet flooring | |
| recommended paired furniture | Pairs with low-profile sofas, modular sectionals, and fabric or leather accent chairs | |
| surface use limitation | Not intended for use as a seating surface or heavy load work surface |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture for domestic use: tables, safety and structural performance requirements | |
|---|---|---|
| EN 15372:2007 | Furniture for non-domestic use: tables, strength and durability requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop substrate quality | |
|---|---|---|
| GB/T 4893.8-2013 | Surface wear resistance test for furniture finishes, applicable to tabletop durability | |
| GB/T 4893.9-2013 | Surface impact resistance test for furniture finishes, applicable to tabletop impact tolerance | |
| GB/T 1732-1993 | Impact resistance test for paint films, applicable to metal frame powder coat quality |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop substrate quality; 2. GB/T 4893.8-2013: Surface wear resistance test for furniture finishes, applicable to tabletop durability; 3. GB/T 4893.9-2013: Surface impact resistance test for furniture finishes, applicable to tabletop impact tolerance; 4. GB/T 1732-1993: Impact resistance test for paint films, applicable to metal frame powder coat quality; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
