Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1200 x 700 x 450 mm | |
|---|---|---|
| lower table top thickness | 30 mm | |
| upper raised tier dimensions | 800 x 600 mm | |
| upper tier height above lower top | 180 mm | |
| lower round plinth base diameter | 500 mm | |
| upper pedestal base dimensions | 400 x 300 mm | |
| storage compartment internal depth | 150 mm | |
| rounded corner radius on lower top | 50 mm | |
| lower body panel thickness | 18 mm | |
| floor clearance under lower body | 20 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| lower top distributed static load | 50 kg | |
|---|---|---|
| upper raised tier static load | 20 kg | |
| product net weight | 45 kg | |
| storage compartment total volume | 0.18 m³ | |
| surface scratch resistance | 2000 cycles | |
| finish stain resistance | Grade 4 | |
| base stability static tilt load | 30 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| lower table top | 12mm black sintered stone veneer with white natural veining, polished finish | |
|---|---|---|
| lower storage body | 18mm E1 grade engineered wood, cream high-gloss UV lacquer finish with rounded edges | |
| lower support plinth | 1.2mm thick powder-coated carbon steel, matte black finish | |
| upper tier top | 15mm MDF core, glossy white lacquer surface with 50mm thick black edge trim | |
| upper tier pedestal | 18mm E1 grade engineered wood, matching cream high-gloss lacquer finish | |
| storage compartment interiors | 12mm melamine-faced engineered wood, light gray interior finish | |
| drawer slides (if fitted) | Cold-rolled steel full-extension soft-close slides, 35mm width | |
| edge banding | 2mm thick PVC edge banding matching finish color, applied to all exposed panel edges | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| two-tier display layout | Offset raised upper tier provides elevated display space separate from main lower surface | |
|---|---|---|
| enclosed lower storage | Concealed compartments in lower body store living room accessories out of sight | |
| easy-clean surface | Polished stone-veneer and glossy lacquer surfaces wipe clean with soft dry cloth | |
| stable plinth support | Wide round steel plinth and rectangular pedestal eliminate wobble on level floors | |
| rounded edge safety | All exposed corners and edges have radius treatment to reduce impact injury | |
| scratch-resistant work surface | Lower stone top resists scuffs from mugs, books and decorative objects | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| residential living room | Placed in front of sofas on area rugs for beverage, book and display use | |
|---|---|---|
| modern apartment lounge | Suits minimalist, cream/black contemporary interior design schemes | |
| home office lounge area | Provides casual surface for guest refreshments and reading materials | |
| small urban studio | Compact footprint and integrated storage suit limited-space living areas | |
| recommended pairing | Matches with light fabric sofas, neutral area rugs and potted green plants |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements for domestic tables, applicable for structural testing | |
|---|---|---|
| EN 13722:2004 | Performance requirements for furniture storage units, applicable to lower compartments | |
| EN 71-3:2019 | Migration of certain elements, applicable for surface finish safety in residential use |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to cabinet and table construction | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable for formaldehyde emission testing | |
| GB/T 4893.4-2013 | Surface wear resistance test for furniture finishes, applicable to lacquer and stone surfaces |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to cabinet and table construction; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable for formaldehyde emission testing; 3. GB/T 4893.4-2013: Surface wear resistance test for furniture finishes, applicable to lacquer and stone surfaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
