Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 500 x 410 x 500 mm | |
|---|---|---|
| Top panel thickness | 25 mm | |
| Plinth base height | 30 mm | |
| Per drawer front height | 205 mm | |
| Corner radius | 20 mm | |
| Recessed handle groove depth | 15 mm | |
| Per drawer internal usable width | 440 mm | |
| Per drawer internal usable depth | 360 mm | |
| Per drawer internal usable height | 175 mm | |
| Base floor clearance | 5 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Top panel static load capacity | 25 kg | |
|---|---|---|
| Drawer glide cycle rating | 50000 open/close cycles | |
| Finish abrasion resistance | 2000 rub cycles | |
| Product net weight | 25 kg | |
| Recommended color option count | 6 | |
| Standard residential warranty | 1 year | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Core cabinet body | 18mm thick E1-grade engineered wood (MDF/particleboard) | |
|---|---|---|
| Top surface and edge trim | Light oak wood veneer over engineered wood core | |
| Drawer front panels | 15mm thick engineered wood with matte off-white polyurethane paint | |
| Drawer box sides/bottom | 12mm thick plywood or solid pine wood | |
| Drawer glides | Cold-rolled steel side-mounted ball-bearing glides with stop latches | |
| Plinth base core | 18mm thick engineered wood with matching oak trim and light grey bottom pad | |
| Recessed handle groove | Integrally routed into drawer divider, no protruding metal hardware | |
| Surface edge treatment | Smooth rounded polyurethane edge banding matching panel finish | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Drawer operation | Two equal-height stacked drawers pull out horizontally with integrated recessed pulls | |
|---|---|---|
| Drawer extension | Full-extension glides allow 100% drawer access to rear storage area | |
| Collision protection | 20mm rounded vertical edges on all exposed corners reduce impact injury risk | |
| Floor protection | Low-friction non-marking felt pad on plinth base prevents floor scratching | |
| Storage function | Dual enclosed drawers conceal personal items, dust and clutter out of sight | |
| Surface utility | Flat level top surface supports table lamps, phones, books and decor items | |
| Stability design | Wide flush plinth base distributes weight evenly to eliminate tipping risk | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Bedroom bedside placement | Position next to standard height beds for overnight storage of phones, books and lamps | |
|---|---|---|
| Living room side table use | Place next to sofas or lounge chairs for remotes, coasters and small decor | |
| Small apartment storage | Suitable for compact studio units where multi-use low storage is required | |
| Hotel guest room furnishing | Match with modern hotel beds for consistent minimalist guest room design | |
| Children’s bedroom use | Soft rounded corners eliminate sharp edge risks for child-safe spaces | |
| Matching interior style | Coordinate with light oak, cream and white modern minimalist or Japandi interiors |
EU Market Access Requirements* EN Standards
| Formaldehyde emission classification | EN 13986:2004+A1:2015 E1 | |
|---|---|---|
| Furniture safety for domestic use | EN 12521:2015 | |
| Surface abrasion resistance | EN 15185:2011 |
Standards applicable to China-market projects
| Formaldehyde emission limit | GB/T 39600E1 grade | |
|---|---|---|
| Surface coating safety | GB 18581 | |
| Hardware durability | GB/T 10357.5 |
This product must meet the following technical requirements: 1. Formaldehyde emission limit: GB/T 39600E1 grade; 2. Surface coating safety: GB 18581; 3. Hardware durability: GB/T 10357.5; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
