| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall nested footprint (rotated open) | 1200 x 900 x 508 mm | |
|---|---|---|
| Upper table diameter | 780 mm | |
| Upper table total height | 508 mm | |
| Lower table diameter | 680 mm | |
| Lower table total height | 457 mm | |
| Upper tabletop thickness | 12 mm | |
| Upper metal frame tube wall thickness | 1.5 mm | |
| Lower drum base wall thickness | 18 mm | |
| Upper frame leg clearance under tabletop | 470 mm | |
| Floor contact pad diameter | 30 mm | |
| Tabletop edge radius | 10 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Upper table static distributed load capacity | 50 kg | |
|---|---|---|
| Set total net weight | 35 kg | |
| Recommended number of users | 4 | |
| Frame rust resistance service life | 5 years | |
| Tabletop scratch resistance rating | Grade 3 | |
| Anti-tip stability rating | Pass for 10° tilt test | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upper table top | 12mm matte black sintered stone with geometric inlay lines | |
|---|---|---|
| Lower table top | 12mm white marble-look sintered stone with natural veining | |
| Upper table frame | 1.5mm thick carbon steel with matte black powder coating | |
| Lower table base | Black matte laminated MDF drum cylinder wrapped in PU finish | |
| Frame weld points | Full arc welded joints with ground smooth finish | |
| Floor protection pads | 30mm diameter silicone anti-slip pads on all base contact points | |
| Surface finish coating | Electrostatic spray powder coat, 60μm thickness on metal parts | |
| Internal core for lower top | High-density E1 grade MDF substrate under stone veneer | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| 360° rotating nesting function | Upper table rotates around central axis to slide over lower table for space saving | |
|---|---|---|
| Full under-table nesting | Lower table slides completely under upper table when not in use to reduce footprint | |
| Waterproof tabletop surface | Non-porous sintered stone surface resists liquid spills for easy cleaning | |
| Scratch-resistant tabletop | Hard sintered stone surface resists scratches from daily items like keys and magazines | |
| Anti-slip base | Silicone floor pads prevent unwanted sliding and protect hard floor surfaces | |
| Collision-safe edges | Rounded polished tabletop edges reduce injury risk from accidental bumps | |
| Tool-free reconfiguration | Tables slide and rotate without disassembly to adjust layout for different uses | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Living room sofa front placement | Positioned in front of 3-seat sofas for placing drinks, magazines and decor | |
|---|---|---|
| Small apartment space saving | Nesting design reduces footprint when extra surface is not needed | |
| Modern minimalist interior style | Black and white contrast finish matches contemporary, light luxury home decor | |
| Balcony casual seating area | Used as side tables for lounge chairs in covered balcony spaces | |
| Office reception lounge | Placed in reception waiting areas for guest beverage and reading material placement |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety strength and durability requirements for domestic tables, applicable for load testing | |
|---|---|---|
| EN 1022:2018 | Domestic furniture seating stability test reference for table anti-tip verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to MDF drum base component | |
|---|---|---|
| GB/T 3325-2017 | General technical requirements for metal furniture, applicable to steel frame component | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable for indoor air safety |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to MDF drum base component; 2. GB/T 3325-2017: General technical requirements for metal furniture, applicable to steel frame component; 3. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable for indoor air safety; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
