| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 600 x 450 mm | |
|---|---|---|
| Top panel thickness | 12 mm | |
| Lower shelf thickness | 8 mm | |
| Frame tube profile | 20 x 20 mm square | |
| Vertical slat spacing | 80 mm | |
| Lower shelf vertical clearance from floor | 150 mm | |
| Clearance between top and lower shelf | 268 mm | |
| Corner weld leg footprint | 20 x 20 mm | |
| Overhang of top past frame | 10 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Net product weight | 22 kg | |
|---|---|---|
| Top surface static load capacity | 50 kg | |
| Recommended maximum user weight for edge seating | 100 kg | |
| Surface abrasion resistance | Class 3 | |
| Recommended number of users | 4 | |
| Top surface heat resistance | 180 °C | |
| Powder coat abrasion cycle rating | 1000 cycles | |
| Frame torsional stability load | 30 kg | |
| Recommended maximum serving capacity | 4 users | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Top surface panel | 12mm white marble-veined sintered stone | |
|---|---|---|
| Structural frame | 20x20mm square steel tube with matte black powder coat | |
| Lower storage shelf | 8mm black tempered safety glass | |
| Floor contact pads | 4mm thick non-slip PE plastic pads | |
| Frame weld joints | Fully ground and powder-coated TIG welds | |
| Top panel edge finish | Straight polished eased edge | |
| Frame surface finish | Matte textured black powder coat | |
| Panel mounting hardware | M6 zinc-plated steel bolts with rubber washers | |
| Frame internal anti-rust treatment | Electrophoretic black primer coating under powder coat | |
| Weld joint finish | Ground smooth and powder-coated to match frame | |
| Adjustable leveling feet thread | M8 steel threaded insert | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up |
Adjustment / rotation / tilt / mobility / storage features
| 2-tier open storage | Full-width upper top for serving and decor, mid-height lower glass shelf for book and accessory storage, no door or drawer enclosures for easy access | |
|---|---|---|
| Fixed non-adjustable structure | Welded frame assembly with no height adjustment, folding, or moving parts for maximum structural stability | |
| Floor protection function | Inset non-slip plastic feet on each leg prevent scuffing of hard flooring and carpet, with minor height adjustment capability of 2mm to level on uneven surfaces | |
| Heat and stain resistant top | Sintered stone top supports placement of hot mugs up to 180°C and resists common household liquid stains without sealing | |
| Open base clearance | 150mm floor clearance allows robot vacuum cleaners to pass underneath the table for easy cleaning | |
| Minimal assembly requirement | Knock-down assembly only requires attaching leg sections to central frame and securing top and shelf panels with included hex key hardware | |
| Fixed rigid structure | Fully welded side frame assemblies, bolted cross-braced connections with no moving adjustment parts for maximum structural stability | |
| Floor protection and leveling | Inset non-slip plastic feet on each leg prevent scuffing of hard flooring and carpet, with 2mm threaded height adjustment to level on uneven surfaces | |
| Stain and heat resistant work surface | Sintered stone top supports placement of hot mugs up to 180°C and resists common household liquid stains without sealing or periodic treatment | |
| Robot vacuum compatible clearance | 150mm minimum floor clearance allows most standard residential robot vacuum cleaners to pass underneath the table for unattended floor cleaning | |
| Knock-down flat pack assembly | Assembly requires attaching 4 leg frame sections to central shelf frame and securing top and shelf panels with included hex key, with 12 total M6 mounting bolts | |
| Fingerprint resistant frame finish | Matte textured powder coat reduces visible fingerprint and smudge marks from daily contact, requiring only dry cloth wiping for cleaning |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 1 | |
|---|---|---|
| Shipping carton dimensions | 1270 x 670 x 120 mm | |
| Gross shipping weight | 26 kg | |
| Shipping volume per unit | 0.102 CBM | |
| Required assembly time | 30 minutes | |
| 20ft GP container loading quantity | 260 units | |
| 40ft HQ container loading quantity | 630 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm |
Recommended spaces / users / usage modes
| Living room main seating area | Positioned in front of 3seater sofas for serving drinks, displaying decor, and storing reading materials, sized to match standard small to medium living room layouts | |
|---|---|---|
| Apartment open plan lounge | Compact open frame design creates visual lightness suitable for small urban apartments without blocking sight lines across open spaces | |
| Reception waiting area | Durable easy-clean top and robust metal frame suitable for light commercial office reception spaces to hold magazines and guest refreshments | |
| Modern minimalist and industrial interiors | Black metal frame and white marble-veined top coordinates with monochrome, Scandinavian, and industrial interior design schemes | |
| Carpeted and hard flooring installations | Non-slip feet prevent damage to both polished hard floors and low-pile carpet, no additional rug pad required for installation | |
| Compact urban apartment lounge | Open slatted frame design creates visual lightness suitable for small urban apartments without blocking sight lines across open plan living spaces | |
| Light commercial reception waiting area | Durable easy-clean sintered stone top and robust metal frame suitable for low-traffic office reception spaces to hold magazines and guest refreshments | |
| Mixed flooring installations | Non-slip leveling feet prevent damage to polished hard floors, tile, and low-pile carpet, no additional rug pad required for stable installation |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength, and durability requirements for residential furniture tables, recommended for structural load testing of frame and panels | |
|---|---|---|
| EN 1022:2019 | Test method for stability of domestic seating and tables, recommended to verify resistance to tipping when weight is applied to table edges | |
| EN 12150-1:2015 | Safety standard for thermally toughened soda lime silicate glass, applicable to the lower tempered glass shelf |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional tolerance, edge finishing, and structural stability verification for this residential coffee table | |
|---|---|---|
| GB/T 4893.4-2013 | Surface abrasion resistance test for furniture surfaces, recommended for verifying the finish durability of the top panel | |
| GB 15763.2-2013 | Safety standard for tempered glass, mandatory for the lower glass shelf to confirm impact resistance and safe breakage characteristics | |
| GB/T 17657-2013 | Test methods for evaluating physical and chemical properties of wood-based panels and surface materials, applicable for top panel stain and heat resistance verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional tolerance, edge finishing, and structural stability verification for this residential coffee table; 2. GB/T 4893.4-2013: Surface abrasion resistance test for furniture surfaces, recommended for verifying the finish durability of the top panel; 3. GB 15763.2-2013: Safety standard for tempered glass, mandatory for the lower glass shelf to confirm impact resistance and safe breakage characteristics; 4. GB/T 17657-2013: Test methods for evaluating physical and chemical properties of wood-based panels and surface materials, applicable for top panel stain and heat resistance verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
