Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1200 × 600 × 455 mm | |
|---|---|---|
| top panel thickness | 25 mm | |
| lower shelf thickness | 18 mm | |
| clearance between top and lower shelf | 250 mm | |
| lower shelf usable dimensions | 1100 x 500 mm | |
| frame leg tube wall thickness | 1.5 mm | |
| corner radius of tabletop | 30 mm | |
| floor clearance under lower shelf front edge | 100 mm | |
| frame leg outermost width at base | 1180 mm | |
| frame leg outermost depth at base | 580 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| tabletop static distributed load capacity | 100 kg | |
|---|---|---|
| product net weight | 42 kg | |
| surface scratch resistance rating | 2000 abrasion cycles | |
| frame static stability load offset | 30 kg | |
| floor protection pad load rating per leg | 15 kg | |
| standard warranty period | 1 year | |
| available finish variants | 2 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| tabletop surface panel | High-gloss white marble-veined engineered panel | |
|---|---|---|
| lower storage shelf panel | Matching high-gloss white marble-veined engineered panel | |
| support frame structure | Matte black powder-coated carbon steel tube | |
| frame surface coating | Epoxy polyester powder coating | |
| panel edge banding | Matching high-gloss white PVC edge banding | |
| frame connection hardware | Zinc-plated steel M6 connector bolts and cross dowels | |
| floor contact pads | Non-slip polyethylene plastic foot pads | |
| panel moisture content | 10% | |
| frame weld points | Ground and smoothed TIG welds | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| lower shelf open storage | Open accessible shelf for books, decorative objects and remote controls | |
|---|---|---|
| rounded corner impact protection | 30mm radius rounded corners on all top panel edges | |
| flat-pack knockdown assembly | Assembled with included hex key and hardware kit in 50 minutes | |
| leveling adjustment | Fixed non-adjustable foot pads with uniform contact height | |
| surface stain resistance | Non-porous high-gloss top resists liquid spills from drinks | |
| structural bracing | Angled side frame members form integrated bracing without crossbars under knee area | |
| static fixed design | No extendable, folding, lifting or moving mechanisms | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| residential living room | Positioned in front of 3seat sofas for holding drinks, snacks and decorative items | |
|---|---|---|
| small apartment open plan spaces | Compact 1200mm length suits small living areas without blocking walkways | |
| office reception lounge areas | Used in visitor waiting areas for holding magazines, refreshments and decor | |
| rental property furnishing | Durable scratch-resistant finish and stable frame suits high-turnover rental use | |
| low-pile carpet or hard flooring placement | Non-slip foot pads suit placement on tile, wood, laminate or short-pile area rugs | |
| modern/contemporary interior schemes | Minimalist geometric frame and glossy marble finish matches minimalist, industrial and modern decor styles |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture for domestic use, strength/durability/stability requirements for tables | |
|---|---|---|
| EN 14749:2016 | Domestic and kitchen storage furniture safety requirements, applicable to lower shelf structure | |
| EN 13722:2004 | Furniture surface resistance to cold liquids, applicable to spill-resistant glossy tabletop |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel components of this coffee table | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to the steel frame structure | |
| GB 18584-2001 | Indoor decoration material furniture harmful substance limit, required for panel formaldehyde emission verification | |
| GB/T 4893.8-2013 | Furniture surface mechanical property test for abrasion resistance, applicable to high-gloss top finish |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel components of this coffee table; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to the steel frame structure; 3. GB 18584-2001: Indoor decoration material furniture harmful substance limit, required for panel formaldehyde emission verification; 4. GB/T 4893.8-2013: Furniture surface mechanical property test for abrasion resistance, applicable to high-gloss top finish; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
