Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1300 x 700 x 550 mm | |
|---|---|---|
| Tabletop thickness | 12 mm | |
| Metal frame tube profile | 40 x 20 mm | |
| Drawer internal dimensions | 600 x 380 x 120 mm | |
| Drawer front panel thickness | 18 mm | |
| Lower slat shelf clearance | 220 mm | |
| Lower slat shelf bar spacing | 35 mm | |
| Recessed electric kettle cutout size | 220 x 370 mm | |
| Adjustable foot height | 10 mm | |
| Tabletop edge overhang | 30 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop static load capacity | 100 kg | |
|---|---|---|
| Net product weight | 42 kg | |
| Recommended user capacity | 4 persons | |
| Adjustable foot level adjustment range | 10 mm | |
| Surface scratch resistance rating | 6 Mohs | |
| Suggested warranty period | 3 years | |
| Recommended seating capacity | 4 persons | |
| Adjustable foot level compensation range | 10 mm | |
| Powder coating adhesion durability | 48 hours | |
| Suggested structural warranty period | 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop | 12mm matte dark sintered stone with subtle gold veining, sealed smooth edge | |
|---|---|---|
| Support frame | Matte black powder-coated carbon steel rectangular tubing, welded corner joints | |
| Drawer body | E1 grade matte black melamine-faced MDF, dovetail or dowel assembled construction | |
| Drawer handle | Brushed polished zinc alloy recessed pull handle | |
| Lower storage shelf | Matte black powder-coated carbon steel parallel slats, welded to frame crossmembers | |
| Adjustable feet | Nylon base with steel threaded stem, non-slip pad | |
| Drawer slides | Cold-rolled steel 3-section full-extension ball bearing slides | |
| Recessed appliance platform | Heat-resistant tempered glass support panel | |
| Drawer front panel | 18mm E1 grade matte black melamine-faced MDF with framed edge detail, affixed to drawer box with confirmat screws | |
| Recessed appliance support platform | 8mm heat-resistant black tempered glass support panel, recessed flush with tabletop surface | |
| Assembly connectors | Zinc-plated M6 hex head confirmat screws and steel cross dowels, standard flat pack furniture hardware | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up |
Adjustment / rotation / tilt / mobility / storage features
| Integrated tea service surface | Dedicated flat recessed zone to mount electric boiling kettle and tea sterilization pot, with routing space for power cord through frame | |
|---|---|---|
| Center storage drawer | Full-extension pull-out drawer located under tabletop center to store tea cups, tools and tea caddies, fitted with single metal pull handle | |
| Lower open slat shelf | Fixed open metal slat shelf below drawer for open storage of tea trays, books, spare tea ware or decor, slatted design prevents dust accumulation | |
| Floor level adjustment | 4 threaded adjustable feet at each leg base to compensate for uneven carpet or hard flooring, eliminate table wobble | |
| Heat-resistant work surface | Sintered stone top withstands direct contact with hot teapots and boiling water up to 180°C without surface damage, suitable for daily tea preparation | |
| Edge protection design | Rounded smooth finished tabletop edges to reduce impact injury during use around seating areas | |
| Cable management access | Open frame design allows power cords for tea appliances to route discreetly along frame members to floor outlets, no sharp edges to damage cord insulation | |
| Integrated tea service zone | Dedicated flush recessed rear tabletop zone to mount electric boiling kettle and tea sterilization pot, with 20mm diameter routing gap for power cord through frame | |
| Angled leg stability design | Outward-angled leg base design increases footprint width by 80mm per side, reducing tip risk when weight is applied to table edges during tea service | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of packages | 1 | |
|---|---|---|
| Packed carton dimensions | 1380 x 780 x 180 mm | |
| Gross packaged weight | 48 kg | |
| Packaged volume per unit | 0.194 CBM | |
| Assembly time | 40 minutes | |
| 40ft HQ container loading quantity | 340 units | |
| Required assembly time | 40 minutes | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm |
Recommended spaces / users / usage modes
| Office reception lounge | Used in executive or visitor reception areas to serve tea to guests, durable stone surface resists wear from frequent daily use | |
|---|---|---|
| Tea room or private club lounge | Dedicated tea service table for formal tea tasting sessions, built-in appliance zone supports dedicated gongfu tea preparation | |
| Apartment open plan living space | Compact 1300mm width fits small to medium living spaces, provides storage for tea items without requiring extra side cabinets | |
| Balcony casual seating zone | Durable powder-coated steel frame resists mild humidity for enclosed balcony use, open slat shelf allows air circulation for stored items | |
| Private tea room or club lounge | Dedicated tea service table for formal gongfu tea tasting sessions, integrated appliance zone supports dedicated boiling water and utensil sterilization setup | |
| Enclosed balcony casual seating zone | Durable powder-coated steel frame resists mild humidity for enclosed balcony use, open slat shelf allows air circulation for stored items to prevent moisture buildup | |
| Studio multifunction space | Low 550mm height works with floor cushions or low lounge seating for casual work, tea service and light dining in small studio layouts |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety requirements for domestic tables, applicable to structural load and stability testing | |
|---|---|---|
| EN 1022:2019 | Furniture - Seating and tables - Determination of stability, applicable to tip resistance during normal tea service use | |
| EN 13722:2004 | Furniture - Test methods for the strength and durability of storage units, applicable to drawer slide performance and structural integrity |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to MDF drawer panel structural performance and finish durability | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, E1 grade (0.124mg/m³) required for all MDF components | |
| GB/T 3325-2017 | General technical requirements for metal furniture, applicable to steel frame welding strength, powder coating adhesion and corrosion resistance | |
| GB/T 4893.4-2013 | Test method for surface finish adhesion and wear resistance for furniture surfaces, applicable to sintered stone and powder coated frame finishes |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to MDF drawer panel structural performance and finish durability; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, E1 grade (0.124mg/m³) required for all MDF components; 3. GB/T 3325-2017: General technical requirements for metal furniture, applicable to steel frame welding strength, powder coating adhesion and corrosion resistance; 4. GB/T 4893.4-2013: Test method for surface finish adhesion and wear resistance for furniture surfaces, applicable to sintered stone and powder coated frame finishes; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
