Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint (nested configuration) | 900 x 900 mm | |
|---|---|---|
| Large tabletop diameter | 900 mm | |
| Large table total height | 450 mm | |
| Small tabletop diameter | 600 mm | |
| Small table total height | 400 mm | |
| Tabletop thickness | 18 mm | |
| Base wall thickness | 2 mm | |
| Arched base cutout clearance height | 100 mm | |
| Floor contact pad diameter | 30 mm | |
| Table edge chamfer | 3 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total set net weight | 20 kg | |
|---|---|---|
| Distributed static load per tabletop | 50 kg | |
| Recommended maximum number of users served | 4 | |
| Surface impact resistance | 12 J | |
| Powder coat finish abrasion resistance | 2000 Taber cycles | |
| Floor protection load capacity per pad | 25 kg | |
| Wobble tolerance on level carpeted surface | 0.5 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | 18mm high-density fiberboard | |
|---|---|---|
| Tabletop surface layer | White marble-veined thermally fused laminate | |
| Tabletop edge banding | 1mm PVC edge seal | |
| Base structure | 2mm cold-rolled steel | |
| Base finish | Matte gunmetal powder coating | |
| Floor contact pads | Non-marking EVA rubber | |
| Assembly hardware | Zinc-plated steel bolts and Allen key | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Nesting functionality | Small table slides 300mm under large table via arched base cutout | |
|---|---|---|
| Independent use capability | Each table functions as a standalone coffee/side table | |
| Surface maintenance | Non-porous sealed tabletop allows wipe-clean with damp cloth | |
| Floor protection | Integrated non-slip pads prevent scratching and sliding | |
| Weight distribution | Three-point base contact ensures stability on uneven carpet | |
| Assembly requirement | Knockdown flat-pack design, tabletop attaches to base with 6 bolts | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Shipping carton dimensions (per carton) | 950 x 650 x 120 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Primary living room placement | Positioned in front of 4seat sectional sofas | |
|---|---|---|
| Small apartment use | Nesting configuration reduces footprint to 0.81sqm when not in expanded use | |
| Reception lounge use | Separated table placement supports guest seating areas for light refreshments | |
| Open-plan flexible space use | Lightweight movable bases allow quick reconfiguration for gatherings | |
| Recommended complementary furniture | Paired with light-toned upholstered sofas and low-pile neutral rugs | |
| Use restriction note | Not intended for heavy weight loads or outdoor use |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic tables, recommended for performanceAcceptancereference | |
|---|---|---|
| EN 1022:2018 | Domestic furniture – Seating and tables – Determination of stability, applicable to anti-tip performance check |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop substrate performanceAcceptancereference | |
|---|---|---|
| GB/T 4893.8-2013 | Furniture surface test for abrasion resistance, applicable to laminate tabletop finish validation | |
| GB/T 1730-2007 | Paint film hardness test, applicable to metal base powder coat durability check |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop substrate performanceAcceptancereference; 2. GB/T 4893.8-2013: Furniture surface test for abrasion resistance, applicable to laminate tabletop finish validation; 3. GB/T 1730-2007: Paint film hardness test, applicable to metal base powder coat durability check; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
