Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 900 × 900 × 460 mm | |
|---|---|---|
| Overall set footprint | 1300 x 900 x 510 mm | |
| Main coffee table dimensions | 900 x 900 x 460 mm | |
| Side table dimensions | 610 x 610 x 510 mm | |
| Main tabletop thickness | 25 mm | |
| Inset rotating tray diameter | 450 mm | |
| Hidden drawer internal depth | 300 mm | |
| Drawer opening height | 80 mm | |
| Side table pedestal base diameter | 280 mm | |
| Main table base wall thickness | 18 mm | |
| Floor clearance under main table | 10 mm | |
| Tabletop edge radius | 20 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Main table distributed static load | 50 kg | |
|---|---|---|
| Side table static load | 20 kg | |
| Drawer rated dynamic load | 10 kg | |
| Set total net weight | 42 kg | |
| Surface scratch resistance | 2000 abrasion cycles | |
| Recommended maximum users around set | 4 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main table base core | E1 grade MDF engineered wood | |
|---|---|---|
| Main table finish | Cream matte polyurethane paint | |
| Side table top and base core | E1 grade MDF engineered wood | |
| Side table finish | Dark charcoal gray matte polyurethane paint | |
| Inset rotating tray surface | Sintered stone laminate overlay | |
| Drawer hardware | Silent 3-section ball bearing slide rails | |
| Drawer recessed pull | Integrated matching painted wood pull | |
| Bottom floor glides | Felt anti-scratch pads | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Nested flexible placement | Side table slides partially under main table edge to save space | |
|---|---|---|
| Hidden drawer storage | Full-width under-top drawer opens via recessed front pull for concealed storage | |
| Rotating inset tray | Centered circular tray rotates 360 degrees for easy access to items across the table | |
| Easy-clean surface | Smooth non-porous matte finish wipes clean with dry or damp cloth | |
| Rounded edge safety | All exposed top and base edges are rounded to eliminate sharp corners | |
| Anti-scratch floor protection | Felt base glides prevent scuffs on hardwood, tile and laminate floors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Small to medium living rooms | Low profile height fits standard sofa seating for lounge use | |
|---|---|---|
| Apartment lounge spaces | Nesting design reduces footprint when not in use for compact layouts | |
| Minimalist wabi-sabi interiors | Two-tone cream and charcoal matte finish matches neutral modern decor schemes | |
| Open concept lounge zones | Movable side table can be repositioned for extra serving space during gatherings | |
| Family household use | Rounded edges and stable solid bases reduce tip risk for children and pets |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Formaldehyde emission | EN 312:2010 | |
|---|---|---|
| Surface resistance | EN 12720:2013 | |
| Structural safety | EN 15372:2016 |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Formaldehyde emission limit | GB/T 18580 | |
|---|---|---|
| Surface coating durability | GB/T 4893.4 | |
| Structural stability | GB/T 10357.1 |
This product must meet the following technical requirements: 1. Formaldehyde emission limit: GB/T 18580; 2. Surface coating durability: GB/T 4893.4; 3. Structural stability: GB/T 10357.1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
