Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 900 × 900 × 470 mm | |
|---|---|---|
| Overall nested set footprint | 900 x 900 x 470 mm | |
| Main table diameter | 900 mm | |
| Main table overall height | 470 mm | |
| Main tabletop thickness | 12 mm | |
| Main central support base diameter (floor contact) | 300 mm | |
| Main angled side support height | 450 mm | |
| Side table diameter | 600 mm | |
| Side table overall height | 450 mm | |
| Side table base diameter (floor contact) | 350 mm | |
| Side table support stem width | 120 mm | |
| Under-table floor clearance (main table) | 100 mm | |
| Nesting overlap depth when tucked | 250 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Main table static distributed load capacity | 100 kg | |
|---|---|---|
| Total set net weight | 42 kg | |
| Tabletop scratch resistance rating | 6 Mohs | |
| Tabletop stain resistance grade | Grade 5 | |
| Metal base anti-rust coating life | 5 years | |
| Recommended maximum number of users for shared use | 4 | |
| Surface heat resistance threshold | 180 °C | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main tabletop | 12mm white sintered stone with grey natural marble veining, matte finish | |
|---|---|---|
| Side tabletop | 12mm black sintered stone with gold linear veining, matte finish | |
| Main table central support | 1.5mm thick welded steel, tapered cone form, matte black powder-coated finish | |
| Main table side support legs | 1.5mm thick folded steel, angled flared form, matte black powder-coated finish | |
| Side table support stem | 2mm thick folded steel, angled cantilever T-form, matte black powder-coated finish | |
| Side table floor base | 2mm thick round flat steel plate, matte black powder-coated finish | |
| Tabletop to base connection hardware | M8 zinc-plated steel screws with rubber anti-slip gaskets | |
| Base floor contact pads | 5mm thick non-slip non-scratch rubber pads | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Space-saving nesting design | Side table slides partially under the main table to reduce footprint when not in use | |
|---|---|---|
| Fixed stable structure | All supports are rigidly mounted to tabletops with no adjustable or moving parts | |
| Multi-surface use flexibility | Side table can be positioned independently next to sofas or armchairs as an end table | |
| Leveling stability | Low center of gravity from weighted steel bases prevents tipping on flat floors | |
| Easy maintenance surface | Non-porous sintered stone tops wipe clean with a damp cloth, no sealing required | |
| Floor protection function | Integrated rubber pads on all base contact points prevent scratches to hard flooring | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room use | Placed in front of 3seat sofas for placing drinks, books, and decorative items | |
|---|---|---|
| Small apartment space optimization | Nesting function reduces required floor space when full surface area is not needed | |
| Modern luxury interior styling | Two-tone stone and matte black sculptural bases complement minimalist, contemporary decor | |
| Lounge reception area use | Suitable for boutique office lounges or hotel lobbies for guest waiting areas | |
| Recommended paired placement | Position side table 300 mm from main table for flexible access during entertaining | |
| Surface compatibility | Suitable for placement on hardwood, tile, and low-pile carpeted floors |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture for domestic use - Tables - Safety requirements, applicable for structural safety testing | |
|---|---|---|
| EN 15187:2006 | Furniture - Test method for assessment of surface resistance to cold liquids |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural stability verification | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in interior decoration wooden furniture, applicable for emission testing | |
| GB/T 4893.4-2013 | Surface wear resistance test for furniture surfaces, applicable for tabletop finish verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural stability verification; 2. GB 18584-2001: Limit of harmful substances in interior decoration wooden furniture, applicable for emission testing; 3. GB/T 4893.4-2013: Surface wear resistance test for furniture surfaces, applicable for tabletop finish verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
