Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 1200 x 600 x 430 mm | |
|---|---|---|
| Tabletop thickness | 47 mm | |
| Vertical side slat diameter | 10 mm | |
| Slat spacing along long sides | 50 mm | |
| Lower shelf grid wire diameter | 6 mm | |
| Floor clearance under lower shelf | 20 mm | |
| Lower shelf usable height clearance | 313 mm | |
| Lower shelf usable depth | 530 mm | |
| Lower shelf usable length | 1130 mm | |
| Corner foot pad diameter | 20 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop static distributed load capacity | 100 kg | |
|---|---|---|
| Product net weight | 30 kg | |
| Recommended maximum number of users for beverage service | 6 | |
| Powder coat finish scratch resistance | 2H pencil hardness | |
| Stone top surface water absorption rate | 0.02% | |
| Frame weld static connection strength | 500 kg per joint | |
| Structural warranty period | 12 months | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop | 1200x600mm dark textured fire-treated stone slab, honed matte finish | |
|---|---|---|
| Perimeter frame and vertical slats | 10mm diameter solid cold-rolled steel bars, matte black powder coating | |
| Lower storage shelf | 6mm diameter steel wire grid, welded to frame, matte black powder coating | |
| Corner support feet | Injection-molded non-slip PP plastic pads, glued to frame base | |
| Top edge trim | 1.2mm thick black steel angle welded to slats to support tabletop | |
| Frame weld points | Fully MIG-welded joints at all slat and grid intersections, ground smooth | |
| Surface finish on metal parts | 70um thick epoxy polyester powder coat, indoor corrosion resistant | |
| Fasteners for tabletop attachment | M6 stainless steel countersunk screws, 16 pieces securing stone to frame | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Fixed height design | 430mm work surface optimized for standard sofa seat heights of 450 mm | |
|---|---|---|
| Open lower grid shelf storage | Provides ventilated open storage for books, magazines and remote controls | |
| Non-slip leveling feet | Prevents floor scratching and stabilizes table on low-pile rugs and hard flooring | |
| Stain-resistant tabletop | Non-porous stone surface supports easy cleaning of beverage spills and tea service residue | |
| Fully welded frame structure | Eliminates loose hardware rattle and provides rigid lateral stability | |
| Open perimeter slat design | Allows 360-degree visibility through frame, maintains light visual profile in small spaces | |
| Edge protection design | Rounded steel top frame prevents sharp edge contact injuries during use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Shipping carton dimensions | 1350 x 750 x 200 mm | |
|---|---|---|
| Gross shipping weight | 33 kg | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential living rooms | Centered on area rug in front of 3-seat sofa and armchairs for tea and beverage service | |
|---|---|---|
| Office reception and lounge areas | Positioned between visitor seating for guest beverage service and reading material storage | |
| Studio apartment open plan spaces | Open slat frame maintains visual lightness while providing two-tier storage in small footprints | |
| Industrial modern interior schemes | Matte black metal and dark stone finish complements concrete, dark wood and leather upholstery | |
| Casual meeting breakout spaces | Provides low-height work surface for informal collaboration and refreshment placement | |
| Recommended complementary pieces | Matching slat-frame side table, matte grey leather seating, low-pile textured area rug |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic tables, applicable to structural performance | |
|---|---|---|
| EN 1022:2018 | Furniture – Seating and tables – Determination of stability, applicable to tip resistance testing | |
| EN 13722:2004 | Furniture – Test methods for surface finishes, applicable to scratch and stain resistance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to stone-top furniture structural safety | |
|---|---|---|
| GB/T 5296.6-2004 | Consumer product instructions for furniture, applicable to product labeling and user guidance | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, applicable to finish emissions |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to stone-top furniture structural safety; 2. GB/T 5296.6-2004: Consumer product instructions for furniture, applicable to product labeling and user guidance; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, applicable to finish emissions; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
