Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2000 x 400 x 500 mm | |
|---|---|---|
| End cap radius | 200 mm | |
| Under-unit floor clearance | 150 mm | |
| Side drawer internal dimensions | 450 x 340 x 120 mm | |
| Central glass cabinet internal width | 800 mm | |
| Adjustable shelf depth inside glass cabinet | 320 mm | |
| Sintered stone top thickness | 12 mm | |
| Glass door panel thickness | 5 mm | |
| Metal leg diameter | 20 mm | |
| Recessed drawer handle cutout depth | 25 mm | |
| Rear cable opening diameter | 60 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Top surface static load capacity | 100 kg | |
|---|---|---|
| Unit net weight range | 65 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Surface abrasion resistance | 2000 revolutions | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Top surface | 12mm matte white sintered stone | |
|---|---|---|
| Main body carcass | E0 grade engineered wood with light taupe matte finish | |
| Side and lower fluted panels | Vertical ribbed engineered wood with light taupe finish | |
| Central cabinet doors | 5mm dark tinted tempered glass | |
| Support legs | Matte black carbon steel tube, powder coated | |
| Drawer slides | Cold-rolled steel soft-close full extension slides | |
| Cabinet hinges | Stainless steel soft-close buffer hinges | |
| Back panel | 8mm thick engineered wood with ventilation cutouts | |
| Adjustable interior shelves | 15mm thick engineered wood with matching finish | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| End drawer storage | Two end soft-close drawers with recessed integrated handles, pull-out access for accessories | |
|---|---|---|
| Central media storage | Two central tinted glass doors enclosing adjustable shelf for AV components | |
| Cable management | Rear pre-drilled cable ports with cover plates for wire routing | |
| Ventilation design | Rear panel ventilation slots to dissipate heat from enclosed AV electronics | |
| Anti-tip safety | Wall anchor hardware included to secure unit to wall for fall prevention | |
| Adjustable shelf height | Central cabinet shelf adjusts to 3 height positions for variable AV component sizes | |
| Floor protection | Non-slip rubber foot pads on each leg to prevent floor scratching | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Living room main wall placement | Positioned below wall-mounted TVs 75 to 85 inches for media storage | |
|---|---|---|
| Open-plan living area use | Low profile does not block sight lines in open concept residential spaces | |
| Modern minimalist interior design | Matches light luxury, contemporary decor schemes with fluted panel detailing | |
| Combined coffee table set use | Pairs with matching fluted round coffee tables for cohesive living room set | |
| Robot vacuum compatible home | 150mm under-clearance allows standard robot vacuums to clean beneath the unit |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety strength and durability requirements for domestic storage furniture | |
|---|---|---|
| EN 14073-2:2004 | Office and home storage furniture safety requirements for storage units | |
| EN 12150-1:2015 | Toughened soda lime silicate glass safety specifications for door panels |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to carcass construction quality | |
|---|---|---|
| GB 18584-2001 | Formaldehyde emission limit for interior decoration wooden furniture, E0 grade compliance | |
| GB/T 28202-2011 | Glass furniture safety requirements, applicable to tempered glass door panels | |
| GB/T 4893.4-1985 | Surface abrasion resistance test for furniture finishes |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to carcass construction quality; 2. GB 18584-2001: Formaldehyde emission limit for interior decoration wooden furniture, E0 grade compliance; 3. GB/T 28202-2011: Glass furniture safety requirements, applicable to tempered glass door panels; 4. GB/T 4893.4-1985: Surface abrasion resistance test for furniture finishes; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
