Automatic mm / inch conversion · Core engineering specifications
| Large table overall size | 800 mm diameter x 500 mm height | |
|---|---|---|
| Small table overall size | 600 mm diameter x 400 mm height | |
| Tabletop thickness | 12 mm | |
| Metal slat width | 20 mm | |
| Metal slat spacing | 30 mm | |
| Large table base ring diameter | 760 mm | |
| Small table base ring diameter | 560 mm | |
| Lower shelf diameter (small table) | 450 mm | |
| Under-large-table clearance height | 470 mm | |
| Floor clearance under base ring | 10 mm | |
| Large table C-frame opening width | 600 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total set gross weight | 48 kg | |
|---|---|---|
| Large tabletop distributed static load | 30 kg | |
| Small tabletop distributed static load | 20 kg | |
| Small table lower shelf static load | 10 kg | |
| Frame static load capacity | 100 kg | |
| Sintered stone surface stain resistance | Level 5 | |
| Powder coat finish abrasion resistance | 2000 cycles | |
| Recommended maximum users | 4 people | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Large tabletop | 12mm thick white marble-pattern sintered stone, polished sealed surface | |
|---|---|---|
| Small tabletop | 12mm thick white marble-pattern sintered stone, polished sealed surface | |
| Structural frame | 1.2mm thick carbon steel with matte black powder coating | |
| Vertical slat supports | Solid 20mm wide carbon steel bars welded to base rings | |
| Lower storage shelf (small table) | Black painted MDF board with smooth matte finish | |
| Base connection hardware | Zinc-plated steel bolts and locking nuts for knockdown assembly | |
| Floor protection pads | 5mm thick non-slip EVA rubber pads pre-fitted to base rings | |
| Frame weld joints | Fully ground and powder-coated smooth welds at slat-to-ring connections | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Nesting space-saving function | Small table slides fully under the large table C-frame opening to reduce footprint | |
|---|---|---|
| Independent use function | Both tables can be separated and used as standalone coffee or side tables | |
| Lower shelf storage (small table) | Open circular shelf provides accessible storage for books, magazines or small decor | |
| Surface cleaning function | Non-porous sintered stone top allows wipe-clean with damp cloth, no sealing required | |
| Floor protection function | EVA pads on base prevent scuffs on hard flooring and reduce movement noise | |
| Knockdown assembly function | Frame and tabletops ship flat for transport, assemble with included hex key in 30 minutes | |
| Stability design | Wide circular base ring distributes weight evenly to prevent tipping on level floors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential living room | Place in front of 4seater sofas for serving drinks, snacks and decor items | |
|---|---|---|
| Small apartment space | Nesting design reduces footprint when not in use, ideal for compact urban homes | |
| Apartment balcony lounge | Use as side/coffee surface for balcony seating areas for casual relaxation | |
| Office reception lounge | Deploy in guest waiting areas for a contemporary, polished look with flexible arrangement | |
| Studio open-plan space | Separate tables to create multiple surface zones for working, dining and entertaining |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture strength, durability and safety for domestic tables, performance guideline | |
|---|---|---|
| EN 10346:2015 | Continuously hot-dip coated steel flat products, applicable to frame material |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to MDF shelf components | |
|---|---|---|
| GB/T 1732-2020 | Paint film impact resistance test, applicable to metal frame powder coating | |
| GB 6566-2010 | Radionuclide limit for building materials, applicable to sintered stone tabletops | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to static load testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to MDF shelf components; 2. GB/T 1732-2020: Paint film impact resistance test, applicable to metal frame powder coating; 3. GB 6566-2010: Radionuclide limit for building materials, applicable to sintered stone tabletops; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to static load testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
