Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1200 x 600 x 430 mm | |
|---|---|---|
| tabletop thickness | 12 mm | |
| frame rod diameter | 10 mm | |
| leveling foot height | 10 mm | |
| under-table floor clearance | 20 mm | |
| top overhang per side | 15 mm | |
| frame base footprint | 1170 x 570 mm | |
| horizontal slat spacing | 30 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| distributed tabletop static load | 100 kg | |
|---|---|---|
| product net weight | 28 kg | |
| tabletop scratch resistance (Mohs) | 6 | |
| tabletop stain resistance class | 5 | |
| powder coat finish abrasion resistance | 2000 cycles | |
| leveling foot adjustment range | 15 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| tabletop | 12mm black veined matte sintered stone | |
|---|---|---|
| frame structure | Matte black powder-coated solid carbon steel rods | |
| frame welds | Ground and powder-coated smooth welded joints | |
| leveling feet | Injection-molded black nylon with steel threaded inserts | |
| frame perimeter trim | 1mm thick black powder-coated steel edge band | |
| frame coating | 80 micron thick epoxy-polyester powder coat | |
| tabletop underside backing | Fiberglass mesh reinforced layer | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| floor leveling adjustment | Threaded feet rotate to adjust height 15mm for uneven surfaces | |
|---|---|---|
| static surface support | Open frame provides even weight distribution across the full tabletop | |
| non-marring floor contact | Nylon feet prevent scuffing on hard flooring and rugs | |
| flat-pack assembly | Frame and top attach with included M6 hex bolts, no special tools required | |
| under-table airflow | Open slatted frame prevents dust buildup and allows rug visibility | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| residential living room | Place in front of sofas or sectionals for beverage and reading material support | |
|---|---|---|
| lounge and reception areas | Use in office break rooms or hotel lobbies for casual guest surface use | |
| small apartment spaces | Open frame maintains visual lightness in compact urban living areas | |
| rug placement | Suitable for placement on low-pile area rugs without blocking carpet patterns | |
| contemporary interior schemes | Matches industrial, minimalist, and modern black-and-neutral decor palettes |
EU Market Access Requirements* EN Standards
| furniture stability | EN 12521:2015 | |
|---|---|---|
| surface safety | EN 14372:2004 | |
| material emissions | EN 13986:2004 |
Standards applicable to China-market projects
| tabletop safety | GB/T 4100 | |
|---|---|---|
| metal frame durability | GB/T 3324 | |
| coating adhesion | GB/T 9286 |
This product must meet the following technical requirements: 1. tabletop safety: GB/T 4100; 2. metal frame durability: GB/T 3324; 3. coating adhesion: GB/T 9286; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
