Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1200 × 600 × 450 mm | |
|---|---|---|
| tabletop thickness | 25 mm | |
| lower shelf usable dimensions | 850 x 500 x 200 mm | |
| vertical slat width on side panels | 20 mm | |
| vertical slat spacing on side panels | 40 mm | |
| frame tube wall thickness | 1.2 mm | |
| corner leg section size | 40 x 20 mm | |
| floor clearance under lower shelf | 150 mm | |
| open side panel height | 400 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| tabletop maximum static distributed load | 113 kg | |
|---|---|---|
| lower shelf maximum static load | 34 kg | |
| product net weight | 25 kg | |
| tabletop surface scratch resistance | 3000 abrasion cycles | |
| frame corrosion resistance rating | Grade 2 (indoor dry use) | |
| recommended maximum number of users | 4 | |
| surface heat resistance for short contact | 80 °C | |
| lower shelf load surface height | 250 mm | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| tabletop panel | Engineered stone composite with white marble-vein polished finish | |
|---|---|---|
| frame structure | Powder-coated carbon steel tubing with matte black finish | |
| vertical side slats | 1.2mm thick matte black steel bars, welded to horizontal frame rails | |
| lower storage shelf | Black laminated particleboard panel fixed to frame cross supports | |
| corner leg feet | Injection-molded PP adjustable foot pads | |
| frame fasteners | Zinc-plated steel hex bolts and cam lock connectors | |
| surface coating on metal | 60μm thick matte black electrostatic powder coat | |
| tabletop edge treatment | Bullnose polished edge matching top surface finish | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| structure type | Fixed non-extendable, non-folding 2-tier open structure | |
|---|---|---|
| lower shelf storage | Open fixed shelf for books, magazines and small decor items | |
| leveling adjustment | Adjustable foot pads with 10mm vertical travel to compensate for uneven floors | |
| surface maintenance | Wipe-clean non-porous top resistant to common household liquid spills | |
| structural load distribution | Welded horizontal cross braces under shelf to prevent frame racking | |
| open side access | Slatted side panels provide open visibility and access to lower shelf items | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| residential living room | Centered in front of sofas for holding drinks, decor and reading materials | |
|---|---|---|
| apartment open plan lounge | Fits small to medium lounge spaces with compact 1200mm width | |
| office reception waiting area | Used as a guest table for magazines and refreshments in reception zones | |
| recommended pairing | Matches fabric or leather 3-seater sofas with 450 mm seat height | |
| surface use suitability | Supports placement of table lamps, potted plants, and serving trays | |
| floor protection | Suitable for use on area rugs, tile, and hardwood flooring with included foot pads |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements for domestic dining/living tables | |
|---|---|---|
| EN 1022:2018 | Stability test standard for domestic seating and tables |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to shelf panel performance | |
|---|---|---|
| GB/T 24821-2009 | General technical requirements for metal furniture, applicable to steel frame structure |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to shelf panel performance; 2. GB/T 24821-2009: General technical requirements for metal furniture, applicable to steel frame structure; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
