Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1400 x 750 x 450 mm | |
|---|---|---|
| Tabletop thickness | 15 mm | |
| Corner radius | 30 mm | |
| Outer leg cross-section | 40 x 20 mm | |
| Inner leg cross-section | 20 x 10 mm | |
| Under-table clearance | 415 mm | |
| Leg splay angle from vertical | 12 degrees | |
| Tabletop overhang front/back | 30 mm | |
| Tabletop overhang sides | 50 mm | |
| Floor contact pad diameter | 20 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Net weight | 40 kg | |
|---|---|---|
| Total static distributed load | 68 kg | |
| Surface scratch resistance | 3000 cycles | |
| Surface water resistance | IPX4 | |
| Recommended placemat weight capacity | 25 kg | |
| Leg frame static load per leg | 25 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop | 15mm white veined sintered stone, polished smooth finish | |
|---|---|---|
| Outer legs (front left, back right) | Powder-coated matte black carbon steel, welded construction | |
| Inner legs (front right, back left) | Brushed gunmetal electroplated stainless steel, welded construction | |
| Frame connection plates | 2mm thick galvanized steel, screwed to tabletop underside | |
| Leg floor pads | Non-slip TPE rubber, adhered to leg bases | |
| Tabletop edge finish | Bullnose polished edge, rounded smooth profile | |
| Metal leg coating thickness | 60 micron powder coat/electroplated finish | |
| Stone substrate moisture content | 0.5% | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Surface use | Flat open top for holding drinks, decor, and reading materials | |
|---|---|---|
| Floor protection | Rubber foot pads prevent floor scratching and sliding | |
| Stability design | Outward-splayed four-leg base prevents tipping under uneven load | |
| Surface maintenance | Non-porous sealed top allows wipe-clean with damp cloth | |
| Assembly requirement | Knock-down assembly with included hex key and hardware | |
| Placement orientation | Designed for centered placement facing a standard 3-seat sofa | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential living room | Positioned centered in front of a 3 m wide sofa for beverage and decor placement | |
|---|---|---|
| Small apartment lounge | Compact open-base design avoids visual clutter in limited floor space | |
| Modern office reception area | Suitable for guest seating areas to hold magazines and refreshments | |
| Recommended pairing | Paired with fabric or leather low-profile sofas 450 mm seat height | |
| Indoor use only | Not rated for outdoor exposure to moisture or extreme temperatures |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic tables | |
|---|---|---|
| EN 13722:2004 | Furniture - Test methods for surface resistance to cold liquids |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to top substrate | |
|---|---|---|
| GB/T 24821-2009 | Performance requirements for metal furniture frames, applicable to leg structure | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to top substrate; 2. GB/T 24821-2009: Performance requirements for metal furniture frames, applicable to leg structure; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
