Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1300 x 700 x 400 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Tabletop static load capacity | 50 kg | |
|---|---|---|
| Product net weight | 42 kg | |
| Drawer open/close cycle rating | 10000 cycles | |
| Door hinge cycle rating | 20000 cycles | |
| Tabletop surface abrasion resistance | 2000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop panel | 18mm E1 grade particleboard with natural oak wood grain laminate | |
|---|---|---|
| Door and drawer fronts | 18mm E1 grade MDF with matte off-white polyurethane paint finish | |
| Cabinet carcass | 15mm E1 grade particleboard with matching off-white melamine finish | |
| Top and bottom edge trim | Solid wood veneer wrapped MDF with oak finish | |
| Drawer slides | Cold-rolled steel full-extension soft-close slides, 45mm width | |
| Cabinet door hinges | Cold-rolled steel soft-close concealed hinges, 35mm cup diameter | |
| Base glide pads | 4mm thick non-slip polyethylene pads at corners | |
| Edge banding | 1mm thick PVC edge banding on all exposed panel edges | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Left hinged cabinet door | Opens 95 degrees outward with soft-close damping, revealing single full-height storage compartment | |
|---|---|---|
| Two stacked right drawers | Pull out fully with soft-close return, providing divided enclosed storage for small living room items | |
| Recessed handleless design | Drawer and door gaps serve as pull points, eliminating protruding hardware for a smooth exterior | |
| Low-profile recessed plinth | Creates floating visual effect, allows easy floor cleaning around the table base | |
| Rounded safety corners | All exposed top corners have rounded edges to reduce impact injury risk | |
| Flat stable worktop | Provides level surface for placing drinks, decorative items, books and serving trays | |
| Floor protection glides | Adjustable low-profile pads at base prevent scuffing on hard flooring | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Gross shipping weight | 48 kg | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Contemporary living rooms | Suits Nordic or minimalist interiors, placed in front of sofas for shared surface use | |
|---|---|---|
| Small apartment spaces | Compact footprint with enclosed storage reduces clutter in limited floor areas | |
| Open plan lounge areas | Neutral finish coordinates with light wood and neutral soft furnishing palettes | |
| Residential media use case | Low height supports placement of media accessories and decorative items under wall-mounted TVs | |
| Family daily use | Smooth matte finish is easy to wipe clean, resistant to common household spills |
EU Market Access Requirements* EN Standards
| Domestic furniture safety requirement | EN 12521:2015 | |
|---|---|---|
| Formaldehyde emission for wood panels | EN 312:2010 E1 class ≤0.124mg/m3 | |
| Surface wear resistance for furniture | EN 15186:2012 |
Standards applicable to China-market projects
| Panel furniture formaldehyde emission | GB/T 39600E1 limit ≤0.124mg/m3 | |
|---|---|---|
| Furniture surface cold/heat resistance | GB/T 4893.3Class 2 | |
| Drawer and door durability | GB/T 10357.5Level 2 |
This product must meet the following technical requirements: 1. Panel furniture formaldehyde emission: GB/T 39600E1 limit ≤0.124mg/m3; 2. Furniture surface cold/heat resistance: GB/T 4893.3Class 2; 3. Drawer and door durability: GB/T 10357.5Level 2; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
