Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 800 x 800 x 460 mm | |
|---|---|---|
| tabletop thickness | 18 mm | |
| frame tube section | 25 x 25 mm | |
| vertical slat width | 20 mm | |
| vertical slat spacing | 40 mm | |
| bottom frame clearance from floor | 10 mm | |
| diagonal cross-brace section | 20 x 20 mm | |
| tabletop edge overhang | 20 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| net weight | 40 kg | |
|---|---|---|
| distributed tabletop static load | 100 kg | |
| surface scratch resistance rating | 3H | |
| powder coating corrosion resistance | 72 hours salt spray | |
| vertical slat side panel impact resistance | 10 J | |
| structure service life reference | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| tabletop substrate | High-density fiberboard core with white marble-veined sintered stone/laminate surface | |
|---|---|---|
| tabletop edge banding | Matching white PVC edge banding with square profile | |
| main frame tubing | 1.2mm thick cold-rolled steel tubing | |
| frame surface finish | Matte black electrostatic powder coating | |
| vertical slat panels | 1.0mm thick flat black steel slats | |
| diagonal corner brace | 1.5mm thick steel cross-brace welded to frame corners | |
| frame weld points | Ground smooth weld joints at all tube intersections | |
| floor contact pads | Non-slip polyethylene plastic pads on frame bottom | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| structural stability | Diagonal corner cross-brace prevents frame racking under uneven load | |
|---|---|---|
| surface utility | Waterproof, easy-clean tabletop suitable for hot beverage placement up to 120°C | |
| base design | Open slatted two-side cage base provides visual lightness without enclosed storage | |
| floor protection | Integrated plastic foot pads prevent scratching of hard flooring and carpet indentation | |
| assembly requirement | Flat-pack design requires bolted assembly of frame components and tabletop attachment | |
| weight distribution | Four-point perimeter frame support evenly distributes load across the tabletop surface | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| residential living room | Centrally placed in front of sofas for beverage, decor and reading material placement | |
|---|---|---|
| small office reception area | Positioned between guest seating for reception areas holding magazines and refreshments | |
| apartment lounge spaces | Compact square footprint fits small urban living rooms without occupying excess floor space | |
| showroom display | Used as display plinth for home decor exhibitions matching minimalist interior design schemes | |
| co-working break areas | Placed in casual breakout zones for employee rest and informal small-group interaction |
EU Market Access Requirements* EN Standards
| furniture stability testing | EN 12521:2015 strength, durability and stability for domestic tables | |
|---|---|---|
| surface resistance to cold liquids | EN 12720:2009+A1:2013 for furniture surface finish performance |
Standards applicable to China-market projects
| tabletop formaldehyde emission | GB/T 17657E1 grade ≤0.124mg/m³ | |
|---|---|---|
| metal furniture structural strength | GB/T 3324 general technical requirements for wooden furniture with metal frames | |
| powder coating adhesion | GB/T 9286cross-cut test grade 1 |
This product must meet the following technical requirements: 1. tabletop formaldehyde emission: GB/T 17657E1 grade ≤0.124mg/m³; 2. metal furniture structural strength: GB/T 3324 general technical requirements for wooden furniture with metal frames; 3. powder coating adhesion: GB/T 9286cross-cut test grade 1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
