Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1400 x 820 x 480 mm | |
|---|---|---|
| tabletop thickness | 25 mm | |
| corner radius | 120 mm | |
| central support column diameter | 60 mm | |
| 4-star base spread diameter | 800 mm | |
| base leg section width | 40 mm | |
| floor clearance under tabletop | 430 mm | |
| base leg wall thickness | 1.5 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| net weight | 25 kg | |
|---|---|---|
| distributed tabletop static load | 50 kg | |
| base static load rating | 75 kg | |
| surface impact resistance | 1.2 J | |
| finish abrasion resistance | 2000 cycles | |
| seating capacity alignment | 3 people | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| tabletop substrate | E1 grade engineered wood board | |
|---|---|---|
| tabletop surface finish | White matte PU paint finish | |
| central support column | Chrome-plated cold-rolled steel | |
| 4-star base legs | Polished chrome-plated steel | |
| base foot pads | Non-slip PE plastic pads | |
| tabletop-base connector | Powder-coated steel mounting bracket | |
| paint film thickness | 80 um | |
| board moisture content | 10% | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| floor protection | Integrated plastic foot pads prevent scratches on hard flooring | |
|---|---|---|
| surface maintenance | Smooth non-porous finish allows wipe-cleaning with damp cloth | |
| load distribution | 4-star base spreads weight evenly to eliminate table wobble on flat floors | |
| edge safety | Rounded tabletop corners eliminate sharp impact points for household and lounge use | |
| assembly method | Knock-down construction requires attaching base to tabletop with included hardware | |
| placement stability | Wide cross base prevents tipping under normal residential lounge load conditions | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| residential living room | Placed in front of 3seat sofas for holding drinks, books and decor | |
|---|---|---|
| office lounge area | Used in reception lounge zones for visitor seating side refreshment placement | |
| small apartment spaces | Compact rounded-corner design fits tight seating areas without sharp edges | |
| boutique waiting areas | Complements soft upholstered seating in salon or clinic waiting spaces | |
| recommended surface care | Wipe spills immediately with soft damp cloth, avoid abrasive cleaners to preserve finish |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture for domestic use, tables: safety strength and durability requirements | |
|---|---|---|
| EN 13722:2004 | Furniture, assessment of surface resistance to cold liquids for tabletops | |
| EN 1022:2018 | Domestic furniture seating and tables stability test method |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop substrate and finish | |
|---|---|---|
| GB/T 1732-2020 | Paint film impact resistance test method, applicable to tabletop surface validation | |
| GB 18584-2001 | Indoor decorating materials limit of harmful substances for wooden furniture | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to static load validation |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop substrate and finish; 2. GB/T 1732-2020: Paint film impact resistance test method, applicable to tabletop surface validation; 3. GB 18584-2001: Indoor decorating materials limit of harmful substances for wooden furniture; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to static load validation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
