Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint (large table extended) | 1200 x 800 x 450 mm | |
|---|---|---|
| Large table tabletop diameter | 800 mm | |
| Large table total height | 450 mm | |
| Small table tabletop diameter | 600 mm | |
| Small table total height | 400 mm | |
| Metal vertical leg tube diameter | 25 mm | |
| Metal base ring tube diameter | 30 mm | |
| Tabletop thickness | 12 mm | |
| Nesting clearance between tables | 55 mm | |
| Large table leg span (base ring diameter) | 700 mm | |
| Small table leg span (base ring diameter) | 520 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Large table static load capacity | 50 kg | |
|---|---|---|
| Total set net weight | 22 kg | |
| Tabletop surface scratch resistance | 3000 cycles | |
| Frame static load stability (tilt resistance) | 15 kg lateral force at table edge | |
| Recommended service life | 5 years | |
| Number of seating positions supported | 4 | |
| Frame joint weld strength | 1000 kgf static pull force | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Large table tabletop | Black stone-effect sintered stone laminate, matte finish with linear geometric groove detailing | |
|---|---|---|
| Small table tabletop | White marble-effect sintered stone laminate, smooth matte finish with faint grey veining | |
| Frame and legs | Cold-rolled steel tube, matte black electrostatic powder coating | |
| Table edge trim | Matching black/white PVC edge banding, flush fit to tabletop | |
| Base connection welds | Fully ground and powder-coated welded joints between vertical legs and circular base ring | |
| Floor contact points | Embedded non-slip PE plastic foot pads at base ring contact points | |
| Tabletop understructure | 15mm thick MDF support panel bonded under decorative top layer | |
| Frame-to-top hardware | M6 x 20mm carbon steel zinc-plated bolts with lock washers, 4 bolts per table | |
| Wood-based panel moisture content | 10% | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Nested storage configuration | Small table slides fully underneath large table to reduce footprint to 800mm diameter for compact storage | |
|---|---|---|
| Surface maintenance function | Non-porous matte tabletop surface wipes clean with dry or damp cloth, resistant to common household water and beverage spills | |
| Floor protection function | Soft PE foot pads prevent scuffs and scratches on hard flooring and low-pile carpet, with no metal parts in direct contact with the floor | |
| Weight transfer stability function | Circular lower base ring distributes weight evenly across 4 floor contact points, preventing wobble on slightly uneven residential floors | |
| Edge safety function | Rounded 2mm radius edges on all tabletop perimeters eliminate sharp corners to reduce impact injury risk for household use | |
| Surface heat resistance | Tabletop withstands 120°C hot item contact without discoloration or delamination for 10 minute exposure | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 1 carton | |
|---|---|---|
| Shipping carton dimensions | 860 x 860 x 120 mm | |
| Gross shipping weight | 25 kg | |
| Shipping volume per set | 0.089 CBM | |
| Assembly time | 20 minutes | |
| 20ft GP container loading quantity | 330 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons |
Recommended spaces / users / usage modes
| Residential living room placement | Positioned in front of 3seat fabric or leather sofas, for serving drinks, displaying decor and holding reading materials during casual seating | |
|---|---|---|
| Small apartment / studio use | Fully nested configuration saves floor space in compact living areas, pulled out to add serving surface when hosting guests | |
| Office reception lounge use | Placed in informal visitor waiting areas to hold beverages, brochures and corporate decor, with durable easy-clean surfaces suitable for high-traffic common areas | |
| Balcony casual lounge use | Placed in enclosed balcony seating areas alongside outdoor lounge chairs for tea or coffee service, with moisture-resistant metal frame and wipe-clean surfaces | |
| Recommended complementary pairing | Pairs with low-pile area rugs and minimalist black/neutral tone seating to match contemporary, industrial or Scandinavian interior styles | |
| Enclosed balcony casual lounge use | Placed in enclosed balcony seating areas alongside outdoor lounge chairs for tea or coffee service, with moisture-resistant powder-coated metal frame that resists up to 70% relative humidity | |
| Rental property furnishing | Supplied as standard furnishing for short-term and long-term rental apartments, with neutral black/white color scheme matching 90% of mainstream interior decor styles, KD construction simplifies replacement of damaged parts |
EU Market Access Requirements* EN Standards
| EN 12521:2015 Furniture - Strength, durability and safety - Requirements for domestic tables | Applicable for structural load, stability and durability testing for residential placement | |
|---|---|---|
| EN 13722:2004 Furniture - Test methods for surfaces - Assessment of surface resistance to abrasion | Applicable for tabletop wear performance validation, recommended minimum 3000 cycles for domestic use | |
| EN 71-3:2019 Safety of toys - Migration of certain elements | Applicable for surface coating heavy metal content if product is used in households with young children |
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable for tabletop panel dimensional tolerance, edge finishing quality and structural stability inspection | |
|---|---|---|
| GB/T 4893.4-2013 Test for surface resistance to dry heat | Applicable for tabletop surface performance acceptance, minimum Class 2 rating recommended for residential use | |
| GB/T 4893.8-2013 Test for surface wear resistance | Applicable for tabletop durability acceptance, recommended minimum 3000 abrasion cycles for residential coffee tables | |
| GB 28007-2011 Safety requirements for children's furniture (general use guidance) | Recommends rounded edge radius of minimum 2mm to reduce impact injury, appropriate for household placement | |
| GB 18580-2017 Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels | Applicable for MDF understructure formaldehyde emission limit, E1 grade required for indoor residential use |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable for tabletop panel dimensional tolerance, edge finishing quality and structural stability inspection; 2. GB/T 4893.4-2013 Test for surface resistance to dry heat: Applicable for tabletop surface performance acceptance, minimum Class 2 rating recommended for residential use; 3. GB/T 4893.8-2013 Test for surface wear resistance: Applicable for tabletop durability acceptance, recommended minimum 3000 abrasion cycles for residential coffee tables; 4. GB 28007-2011 Safety requirements for children's furniture (general use guidance): Recommends rounded edge radius of minimum 2mm to reduce impact injury, appropriate for household placement; 5. GB 18580-2017 Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels: Applicable for MDF understructure formaldehyde emission limit, E1 grade required for indoor residential use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
