Automatic mm / inch conversion · Core engineering specifications
| Overall large table dimensions | 800 mm diameter x 450 mm height | |
|---|---|---|
| Large tabletop thickness | 15 mm | |
| Large table leg height | 390 mm | |
| Large table leg diameter | 30 mm | |
| Overall small table dimensions | 500 mm diameter x 500 mm height | |
| Small table tray rim height | 20 mm | |
| Small table leg cross-section | 25 mm x 25 mm square tube | |
| Storage drawer internal dimensions | 345 mm width x 310 mm depth x 95 mm height | |
| Nesting clearance under large table | 380 mm | |
| Floor to storage body bottom height | 50 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Large table static distributed load capacity | 100 kg | |
|---|---|---|
| Large table total weight | 32 kg | |
| Small table total weight | 8 kg | |
| Tabletop scratch resistance rating | Grade 3 | |
| Adjustable foot pad adjustment range | 10 mm | |
| Recommended maximum placed items per table | 12 items | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Large table tabletop | 15mm sintered stone with polished finish, dark metal edge trim | |
|---|---|---|
| Large table storage body | Cream lacquered MDF composite, 18mm panel thickness, matte finish | |
| Large table legs | Gunmetal black plated carbon steel, curved profile, polished end caps | |
| Small table tray top | Saddle brown faux leather wrapped MDF, raised rolled edge | |
| Small table support frame | Matte black powder-coated carbon steel U-shaped frame, cross base | |
| Storage drawer interior | Anti-scratch flocked fabric lining, full-extension metal slides | |
| Floor contact pads | Non-marring TPE rubber adjustable glides | |
| Hardware connectors | Zinc-plated steel cam lock screws, pre-drilled assembly holes | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Nesting function | Small table slides partially or fully under large table to reduce footprint when not in use | |
|---|---|---|
| Hidden storage access | Two side push-to-open drawers on large table, no visible external handles | |
| Tray top function | Raised edge on small table top prevents decor or drink items from sliding off | |
| Floor leveling | Adjustable glides on all leg bases compensate for up to 10mm of uneven floor | |
| Dual-use small table | Small table can be pulled out to use as an independent side table next to seating | |
| Surface maintenance | Non-porous sintered stone top resists water and common household stains for easy wipe cleaning | |
| Tip resistance | Wide cross base on small table and four-point leg layout on large table reduce tip risk during normal use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Living room main seating area | Positioned in front of 3-seat sofas for placing drinks, books, and decor items | |
|---|---|---|
| Small apartment and open-plan spaces | Nesting function saves floor space when extra surface area is not needed | |
| Transitional side table use | Pull small table out to use as an end table next to armchairs or lounge seating | |
| Modern cream-style interior schemes | Cream body, dark metal accents and leather tray match contemporary warm neutral decor | |
| Light commercial lounge use | Suitable for office reception areas and boutique waiting spaces with low daily traffic | |
| Recommended pairing | Match with light upholstered sofas and low-pile area rugs for a cohesive modern aesthetic |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic tables, applicable for structural load validation | |
|---|---|---|
| EN 14749:2016 | Domestic and kitchen storage units, applicable for drawer slide and storage safety validation |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to the storage body structure | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to composite panel base material checks | |
| GB/T 17657-2013 | Test methods for surface properties of wood-based furniture panels, applicable to finish durability checks |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to the storage body structure; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable to composite panel base material checks; 3. GB/T 17657-2013: Test methods for surface properties of wood-based furniture panels, applicable to finish durability checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
