Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1200 × 600 × 450 mm | |
|---|---|---|
| Overall assembled dimensions | 1200 x 600 x 450 mm | |
| Tabletop thickness | 16 mm | |
| Leg cross-section dimension at mounting point | 20 mm | |
| Corner radius | 50 mm | |
| Front leg clearance span | 1100 mm | |
| Side leg clearance span | 500 mm | |
| Under-table ground clearance | 434 mm | |
| Leg taper diameter at floor contact | 15 mm | |
| Mounting plate diameter at leg-top joint | 30 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed static tabletop load capacity | 45 kg | |
|---|---|---|
| Product net weight | 12 kg | |
| Surface vertical impact resistance | 10 J | |
| Surface abrasion resistance | 2000 cycles | |
| Powder coating rust resistance (indoor use) | 100 hours salt spray | |
| Leveling adjustment range | 5 mm | |
| Recommended maximum user weight for edge sitting | 80 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 16 mm thick MDF board | |
|---|---|---|
| Tabletop surface finish | White marble-pattern melamine laminate | |
| Tabletop edge treatment | Matching laminate sealed edge with rounded profile | |
| Leg construction | Powder-coated matte black carbon steel tubing | |
| Leg mounting hardware | Zinc-plated steel screw fasteners with black plastic end caps | |
| Foot glides | Black nylon non-slip leveling glides | |
| Surface coating layer thickness | 0.1 mm melamine wear layer | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Structure type | Fixed four-corner leg open frame design | |
|---|---|---|
| Assembly requirement | Flat-pack leg attachment to pre-finished tabletop | |
| Surface function | Smooth non-porous easy-clean top for drinks, decor and reading material | |
| Safety feature | Rounded anti-collision table corners | |
| Floor protection | Non-marking nylon glides prevent scratches on carpet and hard flooring | |
| Leveling function | Adjustable foot glides compensate for slight uneven floor surfaces | |
| Disassembly for transport | Legs are fully detachable from tabletop for flat storage and moving | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Single carton outer dimensions | 1250 x 680 x 180 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room placement | Position in front of sofas for holding drinks, remotes, books and decorative items | |
|---|---|---|
| Small apartment and studio use | Compact open-frame design maintains visual lightness in limited floor space | |
| Office reception lounge application | Use in waiting areas for guest refreshments and reading materials | |
| Modern minimalist interior compatibility | Coordinates with monochrome, Scandinavian and contemporary decor schemes | |
| Low-traffic casual space use | Suitable for bedrooms, walk-in closets or home lounge nooks | |
| Recommended cleaning method | Wipe surface with damp soft cloth and mild detergent, avoid abrasive scouring pads |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture strength, durability and safety for domestic tables, applicable to structural performance | |
|---|---|---|
| EN 15187:2007 | Furniture assessment of surface resistance to cold liquids, applicable to top finish testing | |
| EN 1022:2019 | Domestic furniture seating stability reference for occasional table edge load validation |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop substrate performance | |
|---|---|---|
| GB/T 4893.8-2013 | Surface wear resistance test method for furniture surfaces, applicable to laminate top verification | |
| GB/T 4893.1-2021 | Surface resistance to cold liquids test method, applicable to water/stain resistance checks | |
| GB 6675.2-2014 | Toy safety mechanical requirements reference for rounded corner edge safety validation |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop substrate performance; 2. GB/T 4893.8-2013: Surface wear resistance test method for furniture surfaces, applicable to laminate top verification; 3. GB/T 4893.1-2021: Surface resistance to cold liquids test method, applicable to water/stain resistance checks; 4. GB 6675.2-2014: Toy safety mechanical requirements reference for rounded corner edge safety validation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
