Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint (fully extended) | 1200 x 800 mm | |
|---|---|---|
| Large table top diameter | 800 mm | |
| Large table overall height | 500 mm | |
| Small table top diameter | 700 mm | |
| Small table overall height | 400 mm | |
| Table top thickness | 12 mm | |
| Drawer internal usable dimensions | 345 x 310 x 94 mm | |
| Metal base ring diameter (large table) | 760 mm | |
| Metal base ring diameter (small table) | 660 mm | |
| Metal frame tube wall thickness | 1.5 mm | |
| Floor clearance under table apron | 100 mm | |
| Table edge radius | 10 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total set net weight | 35 kg | |
|---|---|---|
| Large table top static distributed load capacity | 50 kg | |
| Table top surface temperature resistance | 120 °C | |
| Surface abrasion resistance | 3000 cycles | |
| Frame structure static load safety factor | 3:1 | |
| Recommended maximum user weight for edge sitting | 100 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Large table top | 12mm white faux marble sintered stone with polished finish, gray veining | |
|---|---|---|
| Small table top | 12mm matching white faux marble sintered stone with polished finish, rounded edges | |
| Small table storage body | 18mm MDF substrate with black wood-grain laminate finish, sealed edges | |
| Large table support frame | 1.5mm thick carbon steel tube with matte black powder coating, C-shaped half-ring base | |
| Small table support frame | 1.5mm thick carbon steel tube with matte black powder coating, circular ring base | |
| Drawer slide hardware | Cold-rolled steel 3-section full extension slides, black finish | |
| Drawer front panel | 18mm MDF with matching black wood-grain laminate, flush fit to body | |
| Foot pads | Non-slip TPE adjustable floor pads, 4 per table base | |
| Fastener hardware | Zinc-plated steel hex bolts and cam lock connectors | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Sliding nesting mechanism | Small table slides fully or partially under large table to reduce footprint by 40% when not in use | |
|---|---|---|
| Integrated small table storage | Single hidden full-circle drawer provides enclosed storage for remotes, coasters and small living room items | |
| Smooth drawer operation | 3-section slides allow 90% drawer extension with soft detent close, no loud slamming | |
| Leveling adjustment | 4 adjustable TPE feet per table compensate for 10mm uneven floor gaps without rocking | |
| Dual-height serving surface | Two height levels allow separate display of decor, snacks and drinks without cluttering a single surface | |
| Scratch-resistant table top | Non-porous polished surface wipes clean with dry cloth, resists daily scuffs from mugs and decor | |
| Knock-down assembly | Frame and tops ship flat, assemble with included hex key in 50 minutes without specialized tools | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Largest carton dimensions | 850 x 850 x 120 mm | |
|---|---|---|
| Second carton dimensions | 720 x 720 x 200 mm | |
| Total shipping gross weight | 35 kg | |
| Total shipping volume | 0.16 CBM | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Small apartment living room | Nesting design saves floor space in compact living areas in front of 3seat sofas | |
|---|---|---|
| Modern minimalist / light luxury interior schemes | Black and white colorway matches monochrome, marble and metal decor palettes | |
| Open plan lounge areas | Two surface heights support casual entertaining, snack service and decor display | |
| Home media rooms | Low profile does not block TV sight lines when placed in front of media consoles | |
| Rental property furnishing | Durable scratch-resistant surfaces and easy assembly suit long-term residential rental use | |
| Lounge waiting areas | Stable construction supports light use in small office reception or lounge zones |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture for domestic use, strength, durability and safety requirements for tables | |
|---|---|---|
| EN 15372:2008 | Surface resistance to cold liquids, heat and abrasion for residential furniture tops | |
| EN 1022:2018 | Stability testing for domestic seating and tables, applicable to tip-over prevention |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to MDF body and laminate finish | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard/MDF requirements for furniture structural use, applicable to cabinet substrate | |
| GB/T 17657-2013 | Test methods for surface physical and chemical properties of wood-based panels, applicable to finish durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to MDF body and laminate finish; 2. GB/T 4897.3-2003: Particleboard/MDF requirements for furniture structural use, applicable to cabinet substrate; 3. GB/T 17657-2013: Test methods for surface physical and chemical properties of wood-based panels, applicable to finish durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
