Automatic mm / inch conversion · Core engineering specifications
| Main coffee table overall dimensions | 990 x 990 x 460 mm | |
|---|---|---|
| Glass top thickness | 12 mm | |
| Main table base diameter | 960 mm | |
| Storage drawer internal dimensions | 350 x 310 x 94 mm | |
| Side table overall dimensions | 700 x 700 x 670 mm | |
| Side table tray top rim height | 20 mm | |
| Side table pedestal column diameter | 120 mm | |
| Side table base diameter | 380 mm | |
| Floor clearance under main table | 10 mm | |
| Drawer front panel thickness | 18 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Main coffee table distributed static load capacity | 34 kg | |
|---|---|---|
| Tempered glass top impact resistance | 1000 mm steel ball drop | |
| Set total net weight | 42 kg | |
| Floor protection glide load rating per glide | 15 kg | |
| Finish abrasion resistance | 400 cycles | |
| Recommended maximum user weight for tray top sitting | 0 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main table top surface | Clear tempered safety glass | |
|---|---|---|
| Main table lower body and drawer front | Walnut-tone wood veneer over MDF core | |
| Main table vertical side support panels | Black fluted ribbed wood composite | |
| Drawer hardware pull | Brushed brass gold-tone round metal knob | |
| Side table tray top | Dark walnut-tone solid wood with raised rim | |
| Side table central column | Dark turned solid wood with stacked bobbin profile | |
| Side table base | Dark stained solid wood with flat circular profile | |
| Internal drawer glides | Side-mounted epoxy-coated steel drawer slides | |
| Floor contact pads | Injection-molded plastic non-scratch glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Main table storage drawer | Single curved front pull-out drawer for small living room accessory storage | |
|---|---|---|
| Glass top surface | Fixed smooth flat surface for holding drinks, decor, and serving items | |
| Side table tray top | Raised-lipped removable tray with central carry knob for portable serving | |
| Side table pedestal base | Fixed stationary pedestal design for stable side placement next to seating | |
| Floor protection | All base contact points fitted with non-scratch glides to prevent hard floor damage | |
| Drawer operation | Smooth pull-out operation with positive stop to prevent full accidental removal | |
| Surface maintenance | Non-porous glass and sealed wood finishes for easy wipe-clean care | |
| Set arrangement flexibility | Side table can be positioned adjacent to main table or standalone as end table | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Primary placement | Positioned directly in front of modular or upholstered sofas in residential living rooms | |
|---|---|---|
| Side table use case | Placed adjacent to sofa armrests for holding drinks, table lamps, or small decor items | |
| Style compatibility | Suits mid-century modern, contemporary, and minimalist interior design schemes | |
| Space suitability | Recommended for small to medium sized living rooms, studio apartments, and lounge seating areas | |
| Surface use cases | Main table supports serving trays, coffee service, decorative vases, and media remotes | |
| Storage use case | Integrated drawer stores remote controls, coasters, magazines, and small living room accessories |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements for domestic living room tables | |
|---|---|---|
| EN 14073-2:2004 | Storage furniture safety requirements applicable to integrated table drawer |
US and Canada office-furniture standards
| ANSI/BIFMA X5.3-2022 | Safety and performance standard for occasional tables used in residential and lounge spaces |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood composite and veneer components | |
|---|---|---|
| GB 15763.2-2005 | Safety requirements for tempered glass used in furniture, applicable to clear glass table top | |
| GB/T 4893.8-2013 | Surface wear resistance test method for furniture finishes, applicable to wood veneer surfaces |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood composite and veneer components; 2. GB 15763.2-2005: Safety requirements for tempered glass used in furniture, applicable to clear glass table top; 3. GB/T 4893.8-2013: Surface wear resistance test method for furniture finishes, applicable to wood veneer surfaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
