Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 1100 x 550 x 450 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Support wall thickness | 1.5 mm | |
| Corner radius of tabletop | 50 mm | |
| Under-table clear height | 380 mm | |
| Support footprint width (single end) | 180 mm | |
| Tabletop overhang beyond supports | 20 mm | |
| Open underpass clear span between supports | 740 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop distributed static load capacity | 45 kg | |
|---|---|---|
| Product net weight | 15.4 kg | |
| Frame rust resistance service life | 3 years | |
| Surface scratch resistance (abrasion cycles) | 2000 cycles | |
| Recommended maximum supported item weight per 100x100mm area | 10 kg | |
| Anti-tip stability load at table edge | 15 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | 18mm MDF engineered wood panel | |
|---|---|---|
| Tabletop surface finish | White marble-vein melamine laminate, scratch and water resistant | |
| Frame and support construction | Integrated bent steel tubing forming continuous edge trim and end legs | |
| Frame surface treatment | Matte black electrostatic powder coating, rust resistant | |
| Foot contact pads | 4mm non-slip rubber pads bonded to base bottom | |
| Edge trim integration | Frame wraps fully around tabletop perimeter with no sharp exposed edges | |
| Surface coating thickness | 60 micron | |
| Board moisture content | 10% | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Fixed height design | No height adjustment, static 450mm working height optimized for sofa-side use | |
|---|---|---|
| Open unobstructed under-storage | Full open central underpass with no crossbars or shelves for flexible basket/ottoman storage | |
| Rounded corner safety design | All tabletop corners have 50mm radius to reduce impact injury risk | |
| Surface spill resistance | Laminate surface allows wipe-clean maintenance with damp cloth, no liquid penetration | |
| Floor protection | Integrated rubber foot pads prevent scratching hard flooring and reduce sliding noise | |
| Fixed assembly structure | No moving parts, hinges, lifts, or extendable mechanisms for long-term stability | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential living room use | Placed in front of sofas for holding drinks, books, decor and remote controls | |
|---|---|---|
| Small apartment space | Compact open-base design fits tight spaces without visual heaviness | |
| Office reception lounge use | Suits modern reception waiting areas for guest beverage and reading material placement | |
| Recommended matching furniture | Pairs with 3-seater sofas 2200 mm wide, lounge chairs, and area rugs | |
| Indoor use only | Designed for dry indoor environments, not suitable for outdoor patio use | |
| Commercial lounge placement | Works in hotel lobbies, co-working break rooms, and cafe lounge zones |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements for domestic tables | |
|---|---|---|
| EN 14749:2016 | Safety requirements for domestic storage and work surfaces, applicable to tabletop stability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop substrate performance | |
|---|---|---|
| GB/T 17657-2013 | Test methods for surface wear resistance and water resistance of wood-based panels | |
| GB 18584-2001 | Limit of formaldehyde emission for indoor wooden furniture, required E1 grade compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop substrate performance; 2. GB/T 17657-2013: Test methods for surface wear resistance and water resistance of wood-based panels; 3. GB 18584-2001: Limit of formaldehyde emission for indoor wooden furniture, required E1 grade compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
