Automatic mm / inch conversion · Core engineering specifications
| Overall main table dimensions | 900 x 900 x 450 mm | |
|---|---|---|
| Main table top thickness | 12 mm | |
| Main table drawer front height | 200 mm | |
| Main table plinth base diameter | 700 mm | |
| Side table top diameter | 550 mm | |
| Side table total height | 500 mm | |
| Side table metal frame wall thickness | 1.5 mm | |
| Side table flat base length | 450 mm | |
| Drawer internal usable depth | 300 mm | |
| Clearance under side table base | 20 mm | |
| Main table rotating plinth height | 50 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Main table distributed static load capacity | 100 kg | |
|---|---|---|
| Main table total net weight | 70 kg | |
| Sintered stone top heat resistance | 1200 °C | |
| Tempered glass impact resistance | 1 kg steel ball drop from 1m | |
| Metal finish corrosion resistance | 500 hours neutral salt spray | |
| Rotating mechanism cycle life | 10000 rotations | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main table top | 12mm dark gray sintered stone with natural marble veining, polished sealed edge | |
|---|---|---|
| Main table drum body | Brushed dark gunmetal carbon steel, 1.5mm wall thickness, anti-fingerprint coating | |
| Main table rotating plinth | Powder-coated solid steel ring with sealed ball bearing swivel | |
| Storage drawer | Cold-rolled steel drawer box with soft-close concealed slides, matching gunmetal front panel | |
| Side table top | 8mm smoked black tempered glass with polished rounded edge | |
| Side table frame | Single bent 1.5mm dark powder-coated carbon steel cantilever support | |
| Side table weighted base | Flat solid steel plate with non-slip felt bottom pads | |
| Hardware components | Zinc alloy concealed drawer handles, stainless steel fastening screws, rubber floor protection pads | |
| Surface finish | Brushed metal with anti-scratch clear top coat, sintered stone with stain-resistant nano-sealant | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| 360-degree rotating main table top | Smooth ball-bearing rotation allows access to storage drawer from any seating position | |
|---|---|---|
| Soft-close integrated storage drawer | Push-to-open front drawer with 300mm internal depth for remote controls and living room items | |
| Slide-under cantilever side table design | Low-profile flat base slides fully under sofas or main table for flexible placement | |
| Stain and heat resistant table tops | Sintered stone and tempered glass surfaces support hot drink placement and easy wipe cleaning | |
| Floor protection design | Felt and rubber pads on all base contact points prevent scratching hard flooring | |
| Pre-assembled construction | Main table and side table ship fully assembled except for optional handle installation | |
| Stable weighted side table support | Solid steel base plate prevents tipping when items are placed on the overhanging top | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Modern living room seating areas | Placed in front of 3-seater sofas for beverage, decor and reading material storage | |
|---|---|---|
| Small apartment open plan spaces | Compact round design and nestable side table reduce footprint in limited spaces | |
| Contemporary lounge and reception areas | Dark metal and stone finish suits upscale office waiting areas and boutique lounges | |
| Flexible side placement | C-shaped side table can be positioned next to accent chairs or chaise longues for individual use | |
| Low-height display use | Smooth polished tops support decorative objects, books and table lamps without visual clutter |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic tables, applicable for structural load testing | |
|---|---|---|
| EN 14073-2:2004 | Office and domestic storage furniture safety requirements, applicable for drawer structural integrity | |
| EN 12150-1:2015 | Thermally toughened soda lime silicate safety glass for furniture, applicable for side table top |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for hardware and structural safety inspection | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard for furniture use, applicable if internal drawer supports use wood-based panels | |
| GB 15763.2-2017 | Safety glazing materials in building, Part 2: Tempered glass, applicable for side table top | |
| GB/T 17657-2013 | Test methods for evaluating surface resistance to scratches, stains and heat for furniture surfaces |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for hardware and structural safety inspection; 2. GB/T 4897.3-2015: Particleboard for furniture use, applicable if internal drawer supports use wood-based panels; 3. GB 15763.2-2017: Safety glazing materials in building, Part 2: Tempered glass, applicable for side table top; 4. GB/T 17657-2013: Test methods for evaluating surface resistance to scratches, stains and heat for furniture surfaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
