Automatic mm / inch conversion · Core engineering specifications
| Overall large table dimensions | 1300 x 700 x 400 mm | |
|---|---|---|
| Overall small table dimensions | 650 x 650 x 550 mm | |
| Large tabletop thickness | 9 mm | |
| Small tabletop thickness | 9 mm | |
| Metal leg tube diameter | 25 mm | |
| Large table cross-brace height | 120 mm | |
| Nesting overlap depth | 400 mm | |
| Leg floor contact spread (large table) | 1100 mm | |
| Leg floor contact spread (small table) | 550 mm | |
| Tabletop edge radius | 30 mm | |
| Floor clearance under large table | 330 mm | |
| Floor clearance under small table | 480 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Large table distributed static load | 100 kg | |
|---|---|---|
| Small table distributed static load | 50 kg | |
| Tabletop surface abrasion resistance | 4000 cycles | |
| Metal frame rust resistance | Grade 2 | |
| Foot pad leveling adjustment | 10 mm | |
| Total set net weight | 25 kg | |
| Recommended maximum place setting items | 8 items | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Large tabletop | 9mm sintered stone-effect panel with grey veined glossy finish | |
|---|---|---|
| Small tabletop | 9mm sintered stone-effect panel with matching grey veined glossy finish | |
| Leg framework | 25mm diameter matte black powder-coated carbon steel tubing | |
| Large table cross-brace | 25mm diameter matching black powder-coated steel tubing | |
| Welded joints | Fully ground and painted steel welds at leg-to-top and brace connections | |
| Foot pads | Non-marking PE plastic adjustable leveling pads | |
| Tabletop edge finish | Polished rounded edge with no sharp corners | |
| Hardware connectors | Zinc-plated steel M6 assembly screws | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Nesting storage function | Smaller taller table tucks partially under larger lower table to reduce floor space by 40% | |
|---|---|---|
| Leveling adjustment | Rotating foot pads at each leg base adjust up to 10mm to stabilize tables on uneven carpet or hard floors | |
| Surface use function | Smooth non-porous tabletop resists water and common household spills, suitable for holding drinks, books, and decorative objects | |
| Impact protection | Rounded polished table edges eliminate sharp corners to prevent collision injury during use | |
| Independent use function | Each table can be used separately as a standalone coffee table or side table when not nested | |
| Floor protection function | Soft plastic foot pads prevent scratches on hard flooring and indentation on low-pile carpet | |
| Assembly function | Knock-down assembly with included hex key and hardware requires no specialized tools | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Primary use space | Modern residential living rooms positioned in front of 3seat sofas | |
|---|---|---|
| Small space application | Studio apartments and compact living areas where nesting saves floor space when not in use | |
| Secondary use case | Transitional side tables pulled beside armchairs or sofas for serving drinks or displaying decor | |
| Matching decor style | Minimalist, industrial, contemporary, and Italian light luxury interior schemes | |
| Recommended placement surface | Low-pile carpet, polished concrete, tile, or hardwood flooring | |
| Target user group | Urban homeowners, rental residents, and apartment dwellers seeking flexible space-saving lounge furniture | |
| Recommended complementary pieces | Low-profile leather sofas, textured fabric sectionals, and neutral-toned area rugs |
EU Market Access Requirements* EN Standards
| Furniture mechanical stability | EN 12521:2015 | |
|---|---|---|
| Surface chemical resistance | EN 12720:2009+A1:2013 |
Standards applicable to China-market projects
| Tabletop mechanical performance | GB/T 17657 | |
|---|---|---|
| Metal frame coating performance | GB/T 13667.1 | |
| Furniture safety general requirements | GB 28007 |
This product must meet the following technical requirements: 1. Tabletop mechanical performance: GB/T 17657; 2. Metal frame coating performance: GB/T 13667.1; 3. Furniture safety general requirements: GB 28007; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
