Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 800 × 800 × 450 mm | |
|---|---|---|
| tabletop thickness | 15 mm | |
| edge trim thickness | 3 mm | |
| pedestal base width | 400 mm | |
| pedestal base depth | 400 mm | |
| pedestal base height | 420 mm | |
| X-brace member width | 40 mm | |
| floor clearance height | 10 mm | |
| X-brace diagonal span | 565 mm | |
| tabletop overhang per side | 200 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| net weight | 50 kg | |
|---|---|---|
| distributed tabletop static load | 100 kg | |
| top surface impact resistance | 6 J | |
| high-gloss finish abrasion resistance | 2000 cycles | |
| floor glide static load per foot | 12.5 kg | |
| recommended placemat heat resistance | 120 °C | |
| base structure lateral stability load | 30 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| tabletop core | Sintered stone, white with subtle grey marble veining | |
|---|---|---|
| tabletop edge band | Black PVC edge trim, 3mm thick | |
| pedestal core | MDF engineered wood panel, 18mm thick | |
| pedestal surface finish | High-gloss black baked polyurethane lacquer | |
| X-brace support | Powder-coated flat steel bar, 40x8mm cross-section | |
| floor glides | Non-marking nylon rubber pads, 2mm thick | |
| structural joinery | M6 steel cam-lock connectors and wood dowels | |
| underside support frame | 18mm MDF bracing frame, attached to pedestal top | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| height adjustment | Fixed 450 mm height, no lift or tilt mechanism | |
|---|---|---|
| floor protection | Non-slip nylon glides under four base corners | |
| surface maintenance | Stain-resistant non-porous top, wipe-clean with damp cloth | |
| structural reinforcement | Integrated X-brace prevents pedestal racking | |
| assembly requirement | Knock-down assembly connecting top to pre-built pedestal base | |
| weight distribution | Central pedestal transfers load evenly to floor contact points | |
| surface usage | Flat level top supports drinks, books, decor and serving trays | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| living room center placement | Positioned in front of 3-seater sofas for beverage and decor placement | |
|---|---|---|
| modern apartment interior | Fits minimalist, light luxury and contemporary interior design schemes | |
| small office reception area | Suitable for low seating reception lounge waiting areas | |
| residential lounge seating group | Placed between two armchairs and a sofa in open-plan living spaces | |
| show home display | Used in property show home staging for contemporary living room setups |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Domestic furniture strength, durability and safety for tables | |
|---|---|---|
| EN 13722:2004 | Furniture surface test methods for resistance to cold liquids |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to base structure | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard/MDF requirements for furniture use, applicable to base substrate | |
| GB 18584-2001 | Indoor decoration material furniture formaldehyde emission limit |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to base structure; 2. GB/T 4897.3-2015: Particleboard/MDF requirements for furniture use, applicable to base substrate; 3. GB 18584-2001: Indoor decoration material furniture formaldehyde emission limit; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
