Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1300 x 700 x 450 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Open lower shelf height (clearance) | 220 mm | |
| Stacked drawer internal height (each drawer) | 140 mm | |
| Open shelf horizontal span | 880 mm | |
| Drawer unit horizontal width | 420 mm | |
| Fluted support column diameter | 320 mm | |
| Fluted rib width (vertical groove) | 12 mm | |
| Plinth base ground clearance | 12 mm | |
| Tabletop edge radius (rounded end) | 350 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop maximum distributed static load | 30 kg | |
|---|---|---|
| Open lower shelf maximum static load | 15 kg | |
| Single drawer maximum static load | 8 kg | |
| Total product net weight | 28 kg | |
| Tabletop surface scratch resistance (coating) | Class 2 abrasion resistance | |
| Tabletop surface heat resistance | 80 °C short-term contact | |
| Product tip stability (side load) | 15 kg lateral side load without tip | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | 18mm thick E1-grade medium-density fiberboard | |
|---|---|---|
| Tabletop finish | 0.6mm thick walnut natural wood veneer with matte polyurethane coating | |
| Drawer box construction | 15mm thick E1-grade particleboard with charcoal grey matte paint finish | |
| Fluted support panel | 12mm thick MDF with vertical ribbed texture, charcoal matte paint | |
| Lower open shelf surface | 15mm thick MDF with matte black painted finish | |
| Plinth base frame | 20mm thick curved MDF with charcoal grey edge banding, matching support color | |
| Drawer slides | 3-section full-extension side-mounted cold-rolled steel slides with zinc plating | |
| Surface coating emission | E1 grade formaldehyde emission (≤0.124mg/m³) | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Drawer operation | Handleless push-to-open mechanism with 300mm slide extension for both stacked drawers | |
|---|---|---|
| Open storage access | Curved front-facing open lower shelf for easy access to displayed items or frequently used objects | |
| Surface maintenance | Stain-resistant matte coating allows wipe-clean with damp cloth, no special polish required | |
| Assembly type | Knock-down flat-pack design with cam-lock connectors for home assembly | |
| Floor protection | Concealed small plastic glides on plinth base to prevent hard floor scratching | |
| Storage zoning | Split layout: enclosed hidden storage in right drawers, open display storage on left lower shelf | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Primary placement | Positioned 400 mm in front of 3-seater sofas in residential living rooms | |
|---|---|---|
| Secondary placement | Small apartment lounge or open-plan studio seating areas | |
| Suitable users | Residential households seeking mixed-style modern/mid-century storage furniture | |
| Recommended use case | Surface placement for drinks, books and decorative objects, with lower storage for remotes, magazines and small living room items | |
| Not recommended for | Commercial high-traffic reception areas or dining/office use | |
| Color scheme compatibility | Pairs with taupe, cream, charcoal or tan upholstered sofas and light wood or matte tile flooring |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements applicable to residential domestic tables | |
|---|---|---|
| EN 13722:2004 | Formaldehyde emission classification requirements applicable to wood-based panel components | |
| EN 15187:2006 | Surface finish impact resistance test applicable to coated furniture surfaces |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements applicable to wooden residential furniture for dimensional and structural safety | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit requirements applicable to wood-based panel components for indoor use | |
| GB/T 4893.8-2013 | Surface wear resistance test method applicable to coated wood furniture surfaces | |
| GB/T 10357.1-2013 | Table furniture static load test method applicable to tabletop and shelf load verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements applicable to wooden residential furniture for dimensional and structural safety; 2. GB 18580-2017: Formaldehyde emission limit requirements applicable to wood-based panel components for indoor use; 3. GB/T 4893.8-2013: Surface wear resistance test method applicable to coated wood furniture surfaces; 4. GB/T 10357.1-2013: Table furniture static load test method applicable to tabletop and shelf load verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
