Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (closed) | 1200 x 700 x 483 mm | |
|---|---|---|
| Tabletop slab thickness | 11 mm | |
| Lifted tabletop height above floor | 688 mm | |
| Ground clearance under plinth base | 15.5 mm | |
| Left drawer internal dimensions | 350 x 400 x 120 mm | |
| Lift-top hidden compartment dimensions | 600 x 500 x 150 mm | |
| Side open storage shelf dimensions | 300 x 400 x 180 mm | |
| Plinth base thickness | 30 mm | |
| Rounded corner radius | 30 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Closed tabletop distributed static load | 91 kg | |
|---|---|---|
| Lift-top elevated working load | 23 kg | |
| Internal storage compartment load limit | 14 kg | |
| Drawer static load capacity | 10 kg | |
| Tabletop surface scratch resistance | 6H pencil hardness | |
| Tabletop heat resistance | 120 °C | |
| Product net weight | 30 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop | 11mm thick white marble-veined tempered glass with polished finish | |
|---|---|---|
| Main body panels | E1 grade medium-density fiberboard with matte white/black textured laminate | |
| Drawer hardware | Zinc alloy square gold-finish pull handle, cold-rolled steel drawer slides | |
| Lift mechanism | Steel soft-close gas strut with locking bracket | |
| Plinth base | 15mm thick black engineered wood with rounded edge profile, small gold-tone metal support feet | |
| Side accent panel | Black textured embossed laminate panel between drawer and lift section | |
| Surface coating | Waterproof, stain-resistant polyurethane topcoat on body panels | |
| Connector hardware | 15mm long confirmat screws, cam lock fittings for flat-pack assembly | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Lift-top operation | Gas strut assisted lift that locks at elevated working height, soft-close when lowering | |
|---|---|---|
| Left drawer access | Full-extension side-mount slide drawer with flush fit, gold pull for open operation | |
| Side open storage | Fixed open shelf compartment adjacent to drawer for frequently accessed items | |
| Hidden under-top storage | Enclosed compartment under lift panel for concealed storage of remotes, blankets | |
| Floor protection | Small raised support feet under plinth base that prevent floor scratching and improve air flow | |
| Rounded edge safety | All tabletop and base corners have smooth rounded profiles to reduce impact injury | |
| Surface cleanability | Non-porous glossy tabletop that wipes clean with damp cloth for daily maintenance | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Living room sofa front placement | Positioned in front of 3-seat sofas in residential living rooms for snack, drink and remote storage | |
|---|---|---|
| Small apartment flexible use | Lift top provides temporary work/dining surface for compact living spaces without extra tables | |
| Light luxury modern interior | Suits contemporary, minimalist, light luxury home decor with black-white gold accent palette | |
| Family daily use | Supports daily use for placing beverages, books, decor and storing living room clutter | |
| Rental property furnishing | Flat-pack design and modern aesthetic suitable for furnished apartment and rental home setups |
EU Market Access Requirements* EN Standards
| Furniture surface durability | EN 12720:2009+A1:2013 | |
|---|---|---|
| Domestic table safety | EN 12521:2015 |
Standards applicable to China-market projects
| Engineered wood emission | GB 18580 | |
|---|---|---|
| Tempered glass safety | GB 15763.2 | |
| Furniture mechanical stability | GB/T 10357.1 |
This product must meet the following technical requirements: 1. Engineered wood emission: GB 18580; 2. Tempered glass safety: GB 15763.2; 3. Furniture mechanical stability: GB/T 10357.1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
