Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 600 x 600 x 500 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Central pedestal column diameter | 76 mm | |
| 4-star base total span across opposite prongs | 550 mm | |
| Individual base prong length from center to tip | 275 mm | |
| Base prong cross-section width | 40 mm | |
| Pedestal column height between tabletop and base junction | 455 mm | |
| Foot glide diameter at each prong tip | 20 mm | |
| Tabletop edge radius | 2 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop static distributed load capacity | 30 kg | |
|---|---|---|
| Product net weight | 15 kg | |
| Tabletop surface stain resistance rating | Level 4 (household liquid wipe-clean) | |
| Chrome base tarnish resistance service life | 3 years dry indoor use | |
| Foot glide floor protection load per prong | 10 kg | |
| Surface impact resistance (tabletop) | 1 J | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | 18mm thick medium-density fiberboard (MDF) | |
|---|---|---|
| Tabletop finish | High-gloss white UV-cured lacquer, 0.2mm coating thickness | |
| Central pedestal column | 1.5mm thick chrome-plated cold-rolled steel, polished mirror finish | |
| 4-star base prongs | 2mm thick die-cast aluminum with polished chrome plating, angular reinforced profile | |
| Foot glides | Injection-molded black polypropylene with non-marking felt pad | |
| Connection hardware | Zinc-plated steel threaded bolts and lock nuts | |
| Finish surface hardness | 2H pencil hardness | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Assembly method | Knock-down self-assembly, 3 main components (top, column, base) secured with included hardware | |
|---|---|---|
| Surface cleaning feature | Non-porous glossy top allows immediate wipe-down of spills without staining | |
| Floor protection feature | Raised non-slip foot glides prevent metal prong contact with floor surfaces | |
| Stability design | 4-point wide star base distributes weight evenly to prevent tipping on level surfaces | |
| Usage position | Fixed height, designed for placement adjacent to seating for beverage and small item storage | |
| Leveling adjustment | 0 to 5mm height adjustment per foot glide to accommodate uneven floors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential living room | Place in front of sofas or armchairs to hold drinks, books, and decorative items | |
|---|---|---|
| Modern office lounge | Pair with visitor seating in reception or breakout areas for guest refreshment placement | |
| Small apartment studio | Compact 600mm diameter footprint fits tight spaces without restricting walkway room | |
| Hotel guest room | Install beside lounge seating as a compact side table for guest amenities |
EU Market Access Requirements* EN Standards
| Surface scratch resistance | EN 15187:2006 Level 3 requirement | |
|---|---|---|
| Load bearing safety | EN 12521:2015 domestic table strength requirement |
Standards applicable to China-market projects
| Tabletop formaldehyde emission | GB/T 18580E1 requirement | |
|---|---|---|
| Metal base coating adhesion | GB/T 9286Grade 1 requirement | |
| Furniture structural stability | GB/T 10357.1static load test requirement |
This product must meet the following technical requirements: 1. Tabletop formaldehyde emission: GB/T 18580E1 requirement; 2. Metal base coating adhesion: GB/T 9286Grade 1 requirement; 3. Furniture structural stability: GB/T 10357.1static load test requirement; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
