Automatic mm / inch conversion · Core engineering specifications
| Overall set nested footprint | 1000 x 1000 x 500 mm | |
|---|---|---|
| Large coffee table diameter | 1000 mm | |
| Large coffee table height | 480 mm | |
| Small nesting table diameter | 600 mm | |
| Small nesting table height | 500 mm | |
| Tabletop thickness | 20 mm | |
| Base vertical support width | 180 mm | |
| Base metal wall thickness | 1.5 mm | |
| Rounded tabletop edge radius | 10 mm | |
| Nesting clearance between tables | 80 mm | |
| Foot pad diameter | 30 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total set net weight | 45 kg | |
|---|---|---|
| Large table distributed static load | 80 kg | |
| Small table distributed static load | 30 kg | |
| Surface finish abrasion resistance | 2000 cycles | |
| Metal frame rust resistance rating | Grade 2 (indoor use) | |
| Wood panel moisture content | 10% | |
| Leveling foot adjustment range | 10 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Large tabletop | Polished black-and-white veined marble-patterned sintered stone | |
|---|---|---|
| Small tabletop | Matching veined marble-patterned sintered stone | |
| Metal base frame | Polished chrome-plated 304 stainless steel | |
| Vertical base panels | Dark ribbed black wood veneer over MDF core | |
| Tabletop substrate | High-density E0 grade particleboard core (if faux stone) | |
| Connecting hardware | Zinc-plated steel M8 connector bolts | |
| Leveling feet | Nylon-tipped adjustable steel foot pads | |
| Edge treatment | Seamless polished rounded stone edge | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Nesting space-saving design | Smaller taller table slides partially under the lower larger table | |
|---|---|---|
| Dual-use configuration | Separated tables function as primary coffee table + side end table | |
| Floor leveling adjustment | Rotating nylon foot pads compensate for 10 mm floor unevenness | |
| Stain-resistant tabletop surface | Non-porous polished finish resists liquid spills and marks | |
| Anti-scratch base design | Nylon foot pads prevent scuffing on hardwood, tile, or carpet floors | |
| Tool-light assembly | Frame attaches to tabletop with included hex key hardware | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Contemporary living room primary seating area | Pairs with modern sofas for coffee, display, and casual use | |
|---|---|---|
| Studio apartment small-space layout | Nesting function reduces footprint when extra surface is not needed | |
| Reception lounge and waiting areas | Coordinates with modern lounge seating for guest beverage placement | |
| Bedroom side accent use | Smaller table can be used standalone as a bedside or dressing side table | |
| Recommended matching furniture | Low-profile fabric/leather sofas, minimalist media consoles, chrome accent lighting |
EU Market Access Requirements* EN Standards
| Residential furniture safety requirements | EN 12521:2015 strength and stability for tables | |
|---|---|---|
| Formaldehyde emission from wood panels | EN 312:2010 E1 class limit | |
| Surface resistance to cold liquids | EN 12720:2009 level 3 |
Standards applicable to China-market projects
| Tabletop formaldehyde emission | GB/T 18580E0 limit | |
|---|---|---|
| Metal furniture structural safety | GB/T 3324 general technical requirements | |
| Furniture surface coating adhesion | GB/T 4893.4cross-cut test grade 1 |
This product must meet the following technical requirements: 1. Tabletop formaldehyde emission: GB/T 18580E0 limit; 2. Metal furniture structural safety: GB/T 3324 general technical requirements; 3. Furniture surface coating adhesion: GB/T 4893.4cross-cut test grade 1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
