Automatic mm / inch conversion · Core engineering specifications
| Overall set dimensions (large table) | 810 mm diameter x 430 mm height | |
|---|---|---|
| Small table dimensions | 700 mm diameter x 300 mm height | |
| Inset table top thickness | 12 mm | |
| Upholstered side wall thickness | 80 mm | |
| Top inset recess depth | 10 mm | |
| Base contact diameter (large table) | 780 mm | |
| Small table tabletop diameter | 580 mm | |
| Vertical seam spacing on upholstery | 200 mm | |
| Floor clearance under units | 0 mm | |
| Nesting offset gap between units | 100 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Combined set net weight | 36 kg | |
|---|---|---|
| Large table distributed static load capacity | 50 kg | |
| Upholstery foam density | 35 kg/m³ | |
| Upholstery foam thickness | 40 mm | |
| Faux leather surface abrasion resistance | 50000 cycles | |
| Sintered stone top scratch resistance (Mohs) | 6 | |
| Recommended maximum number of users | 4 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| External upholstery covering | Matte faux leather (PU) | |
|---|---|---|
| Inset table top surface | Dark sintered stone (rock slab) | |
| Internal support frame | 1.2 mm thick carbon steel tube | |
| Side padding material | High-resilience polyurethane foam | |
| Top edge trim | Matching faux leather binding | |
| Bottom base pad | Non-slip non-woven fabric | |
| Stitching thread | High-tenacity polyester thread | |
| Structural connectors | M6 steel bolts and brackets | |
| Top finish coating | Matte anti-fingerprint nano-coating | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Nesting space-saving function | Manual repositioning of small unit adjacent to large table | |
|---|---|---|
| Tray-style top containment | 10 mm raised lip around inset top | |
| Floor stability design | Full-perimeter flush floor contact | |
| Fixed non-adjustable structure | Permanent assembled form with no tilting, lifting or folding parts | |
| Impact-resistant soft exterior | Padded upholstered sides absorb accidental bumps | |
| Surface cleaning compatibility | Wipe-clean faux leather and sintered stone surfaces | |
| Modular arrangement flexibility | Two independent units can be separated for side table use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Primary living room placement | Positioned in front of 3-seater upholstered sofas in modern residential living rooms | |
|---|---|---|
| Small apartment application | Ideal for compact living spaces under 20 sqm | |
| Show home and model suite use | Suitable for real estate show homes and designer interior projects | |
| Lounge and reception area use | Appropriate for boutique office lounges and residential reception spaces | |
| Recommended pairing | Pair with low-pile carpet and curved fabric/leather sofas | |
| Secondary use cases | Small unit can be deployed as standalone side table beside armchairs |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic tables, applicable for load performance verification | |
|---|---|---|
| EN 15187:2007 | Furniture - Assessment of surface resistance to cold liquids, for spill resistance testing of top surfaces |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural frame and finish quality checks | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wood furniture, for formaldehyde and heavy metal content verification | |
| GB/T 16799-2008 | Technical specifications for polyurethane synthetic leather, applicable to faux leather upholstery quality checks |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural frame and finish quality checks; 2. GB 18584-2001: Limit of harmful substances in wood furniture, for formaldehyde and heavy metal content verification; 3. GB/T 16799-2008: Technical specifications for polyurethane synthetic leather, applicable to faux leather upholstery quality checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
